Specifications
Brand Name :
ISUZU
Model Number :
CL5161GSXS1
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS
Place of Origin :
China
MOQ :
1 UNIT
Price :
USD 61200- USD 64200/ UNIT
Delivery Time :
45-60 work days
Cleaning Process :
Cold Water Cleaning
Condition :
New
Truck :
Street Sweeper Truck
Gvw :
16000kg
Truck Name :
Road Cleaning Truck
Truck Type :
Vacuum Sweeper Truck
Tire :
10.00-20
Dimensions :
8580*2490*3100 mm
Drive Type :
LHD
Transport Package :
Nude Packing, Polished with Wax, Roro or Bulk Ship
Specification :
8000L water tank and 4000L garbage tank
Type :
Wet-type
Transmission Type :
Manual
Emission Standard :
Euro 5
Fuel :
Diesel
Customization :
Available | Customized Request
Description

ISUZU FTR 205hp Medium Duty 15000 Liters Road Street Sweeper Truck

Product Description



Road sweeper truck is also called street sweeper truck, street cleaning truck, road sweeper vehicle.
it combine the function of road sweeping, garbage collection and garbage transportation , is new type efficient sanitation special cleaning vehicle.
It is made of chassis, vice engine, air blower, electromagnetic valve, dust tank, water tank, sucker,
sweeper brush,spraying water system, hydraulic system, electric control system, etc.

It is mainly used to sweep the road garbage of street, highway,dock, station, square,cement mill,

electric power plant, etc.



Product Parameters
Vehicle performance and parameters
Item Parameter Unit
Working Performance Max sweep width 3.5 m
Sweep speed 3-20 km/h
Max sweep capacity 70000 m2/h
Max inhalation of granularity ≥120 mm
Angle of unloading ≥45 .
Volume of water tank 5000 L
Volume of garbage tank 7000 L
Driving Performance Max speed 95 km/h
Max gradeability 30 %
Braking distance ≤10 m
Min turning diameter ≤13.6 m
Quality Parameter Curb weight 9800 kg
GVW 16000 kg
Dimension Parameter Overall dimensions 8090×2470×3050 mm
Wheelbase 4700 mm
Track front 1680 mm
Track rear 1640 mm
Front suspension 1430 mm
Rear suspension 1960 mm
Approach angle 20 .
Departure angle 12 .
Minimum Ground Clearance 240 mm

Product Images

ISUZU FTR 205hp Road Street Sweeper Truck Medium Duty 15000 Liters

ISUZU FTR 205hp Road Street Sweeper Truck Medium Duty 15000 Liters


Product Details

ISUZU FTR 205hp Road Street Sweeper Truck Medium Duty 15000 Liters
