12 Volt 38AH Deep Cycle Hybrid Gel Battery with Copper Terminal and 12 Years Designed Life
12 Volt 38AH Deep Cycle Hybrid Gel Battery with Copper Terminal and 12 Years Designed Life
Specifications
Nominal Voltage :
12 Volt
Battery Designed Life :
12 Years
Dimension :
L197*W165*H170mm
Screw Hole Size :
M6
Rated Capacity :
38AH
Brand Name :
FBATTERY
Approx Weight :
13.2KG
Application :
Photovoltaic System, Hybrid Power System, Power Storage
Battery Case :
ABS
Type :
Deep Cycle Hybrid Gel Battery 12 Volt 38AH
Model Number :
6GFMJ-38
Certification :
CE UL ISO9001 ISO14001
Place of Origin :
Wuhan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T L/C,D/A,D/P
Supply Ability :
10000PCS/30Days
Delivery Time :
30DAYS
Packaging Details :
Carton and Wooden Pallet
Description
Power Storage Deep Cycle Hybrid Gel Battery 12 Volt 38AH Copper Terminal
Product Overview

The Power Storage Deep Cycle Hybrid Gel Battery combines advanced gel technology with robust construction for reliable energy storage applications.

Key Advantages
  • Safety seal with deflating system for simple maintenance
  • Long-lasting performance with stable quality and high reliability
  • Gelled electrolyte made by mixing sulfuric acid with silica fume
  • Non-leaking gel electrolyte enabling uniform plate reaction
  • High rate discharge performance through tight assembly technology
  • Strong heat dissipation and wide operating temperature range
  • Environmentally friendly with no acid mist separation
  • Efficient venting system automatically releases excessive gas
  • More than 260 cycles at 100% depth of discharge
Product Structure & Working Principle

Positive Plate: Thick high Sn low Ca grid with high density paste

Negative Plate: Over-designed capacity to overcome sulphation in low state of charge

Separator: Advanced AGM separator

Electrolyte: Dilute high purity sulfuric acid with nano gel

Battery Container and Cover: ABS material

Pillar Seal: 100% factory tested, proven two layers epoxy resin seal

Relief Valve: Complete with integrated flame arrestor

Technical Specifications
Type Gel Deep Cycle Battery
Nominal Voltage 12V
Rated Capacity 38Ah @ 10HR-rate (to 1.80Vpc)
Approx Dimensions (mm) L197 × W165 × H170mm
Battery Designed Life 12 years
Approx Weight 13.2kg
Applicable Temperature -40℃ to 60℃
Optimum Temperature 20℃ to 25℃
Self-discharge <0.1% per day (20℃)
Materials for Battery Containers and Covers ABS
Terminal Type (mm) Female Copper Insert M6 (torque: 6-8N.m)
Internal Resistance 0.0095 Ohm (fully charged @ 25°C)
Max. Charge Current 9.5A
Max. Discharge Current (5S) 500A
Short Circuit Current 1250A
Performance Characteristics

Constant Current Discharge Ratings

12 Volt 38AH Deep Cycle Hybrid Gel Battery with Copper Terminal and 12 Years Designed Life

Constant Power Discharge Ratings

12 Volt 38AH Deep Cycle Hybrid Gel Battery with Copper Terminal and 12 Years Designed Life
Application Fields

This battery series is ideal for energy storage in renewable energy systems including photovoltaic (PV) solar, wind turbine power systems, and CATV applications.
