12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
Specifications
Nominal Voltage :
12V
Battery Designed Life :
12Years
Maintenance Type :
Free
Terminal Type :
Female Copper Insert M8
Rated Capacity :
120AH
Type :
Storage Gel Battery
Approx Weight :
38KG
Model Number :
6GFMJ-120
Certification :
CE UL ISO9001 ISO14001
Place of Origin :
Wuhan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T L/C,D/A,D/P
Supply Ability :
10000PCS/30Days
Delivery Time :
30DAYS
Packaging Details :
Carton and Wooden Pallet
Application :
Energy Storage for Renewable Energies
Brand Name :
FBATTERY
Battery Case :
ABS
Description
Sealed 12V120AH VRLA Deep Cycle Gel Marine Battery Female Copper Insert M8
Product Overview

12V120AH Sealed VRLA Gel Type Rechargeable Battery Gel Deep Cycle Battery Deep Cycle Marine Battery

Product Features

The storage series is designed for frequent cyclic charge and discharge applications under extreme environments. By combining the newly developed Nano Gel electrolyte with high density paste, the Solar range offers high recharge efficiency at very low charge current. The acid stratification is highly reduced by adding Nano Gel.

Product Structure and Working Principle
  • Positive plate: Thick high Sn low Ca grid with high density paste
  • Negative plate: Over designed capacity to overcome sulphation in low SOC
  • Separator: Advanced AGM separator
  • Electrolyte: Dilute high purity sulphuric acid with nano gel
  • Battery container and cover: ABS
  • Pillar seal: 100% factory tested, proven two layers epoxy resin seal
  • Relief valve: Complete with integrated flame arrestor
Specifications
Type Storage Gel Battery
Nominal Voltage 12V
Rated Capacity 120Ah@10HR-rate (to 1.80Vpc)
Approx Dimensions (mm) L409mm x W177mm x H225mm
Battery designed life 12 years
Approx Weight 38kg
Applicable Temperature -40℃～60℃
Optimum Temperature 20℃～25℃
Self-discharge Self-discharge rate＜0.1% per day (20℃)
Materials for Battery Containers and Covers ABS
Terminal Type (mm) Female Copper Insert M8 (torque: 8～10N.m)
Max. Charge Current 30A
Max. Discharge Current (5s) 960 A
Short Circuit Current 3000 A
Internal Resistance Approx. 0.004 Ohm (fully Charged @ 25℃)
Constant Current Discharge Ratings

Amperes at 25°C

12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
Constant Power Discharge Ratings

Watts at 25°C

12V 120AH Sealed VRLA Deep Cycle Gel Battery with Female Copper Insert M8 for Marine Use
Application Fields

This series is suitable for energy storage for renewable energies such as PV, wind turbine power systems and CATV.

Advantages
  • Long Life: 12 years design life in floating condition
  • Up to 5 years design life at renewable energy applications according to IEC61427
  • Wide operating temperature range from -25°C to 65℃
  • Nano gel electrolyte eliminate the acid stratification and prolong cycle life
  • Round trip efficiency as high as 85%
  • Thick positive flat plate design with high Tin low Calcium alloy and high density paste
  • Low self-discharge rate and long shelf life (9 months at 20℃)
  • Excellent deep discharge recovery capability
