White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
White High Temperature Ceramic Insulation Board Fireproof Furnace Kiln Insulation Board
Specifications
Brand Name :
SUNWOOL
Model Number :
1260C 1350C 1430C 1600C
Certification :
ISO CE
Place of Origin :
CHINA
MOQ :
10 pcs
Price :
Negotiable
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
1000 tons/month
Delivery Time :
15 days
Packaging Details :
Carton Box
Refractoriness :
1050-1800C
Size :
Customizable
Package :
bag or carton box or pallet
Shape :
Customizable
Color :
White
Type :
blanket board module paper textile
Description

1260C 1430C 1600c Ceramic Fiber Board Thermal Insulation Fireproof Board Furnace Kiln Insulation


Ceramic fiber board is a high-performance insulation product made of high-purity ceramic fiber by adding the right amount of organic matter and binder. It is flat, ceramic materials are evenly distributed, free of asbestos and environmental protection. ceramic fiber insulation boards solid texture, wind erosion resistance, excellent toughness and other advantages make it an ideal material for kilns, pipes and other insulation types of equipment. It has low thermal conductivity and low thermal storage, and no expansion during heating, which can reduce energy cost and cycle time, and protect the surface of refractory from thermal shock and chemical attack.

Fire resistant ceramic fiber board advantage:

1, with high temperature thermal conductivity, light weight, long life, tensile strength, good elasticity, non-toxic and so on.
2, high compressive strength, long service life;
3, low heat capacity, low thermal conductivity;
4, non-brittle material, good toughness;
5, the size of accurate, good flatness;
6, easy to install,
7, excellent anti-wind erosion performance;
8, continuous production, fiber distribution, performance and stability;
9, excellent sound and noise reduction performance.


Specification
Type
COM
ST
HP
HA
Zir-Alu
HZ
Classified Temp.
1100ºC
(1983ºF)
1260ºC
(2300ºF)
1260ºC
(2300ºF)
1360ºC
(2480ºF)
1400ºC
(2550ºF)
1430ºC
(2600ºF)
Working Temp.
<1000ºC
(2012ºF)
1050ºC
(1922ºF)
1100ºC
(2012ºF)
1200ºC
(2192ºF)
1200ºC
(1192ºF)
1350ºC
(2462ºF)
Color
white
white
white
white
white
white
Density(kg/m3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
Linear Shrinkage (%)
(24 hrs)
-3
(1000ºC/1832ºF)
-3
(1000ºC/1832ºF)
-3
(1100ºC/2012ºF)
-3
(1250ºC/2282ºF)
-3
(1000ºC/2012ºF)
-3
(1350ºC/2462ºF)



Thermal conductivity
(W/M.K)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
Compression Strength
(Mpa)
0.5
0.5
0.5
0.5
0.5
0.5

Chemical(%)
Al2O3
44
46
47-49
52-55
45-46
39-40
Al2O3+SiO2
96
97
99
99
-
-
Al2O3+SiO2+ZrO2
-
-
-
-

99
ZrO2
-
-
-
-
.5-7
15-17
Fe2O3
<1.2
<1.0
0.2
0.2
0.2
0.2
Na2O+K2O
≤0.5
≤0.5
0.2
0.2
0.2
0.2
Size(mm)
1200*1000mm(47″*40″); 1000*600mm(40″*36″);900*600mm(24″*36″)
20-50mm(1″/2″)thickness


Product Application:

Fire resistant ceramic fiber board applications:

1.Industrial kiln wall lining, masonry insulation layer, high temperature, high heat equipment insulation, insulation, high temperature kiln kiln lining, kiln car, door baffle, furnace furnace temperature divider, aerospace, shipbuilding insulation, Fireproof, soundproof, insulated.
2.Iron and steel industry: expansion joints, insulation, insulation and insulation; non-ferrous metal industry: backing insulation materials, tundish and tank cover for pouring copper and copper alloy;
3.Ceramic industry: light kiln car structure and the furnace hot surface lining, the furnace temperature zone separation and fire materials; Glass industry: the pool was lining heat, burner block;
4.Furnace building: hot surface refractories (alternative fiber blanket), heavy refractory lining, expansion joints;
5.Light industry: lining of industrial and domestic boiler combustors;
6.Petrochemical industry: high temperature heating furnace lining hot surface material;
7.Building materials industry: cement rotary kiln and other equipment insulation.
