1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces
Specifications
Brand Name :
SUNWOOL
Model Number :
1260C 1350C 1430C
Certification :
ISO CE
Place of Origin :
CHINA
MOQ :
50 pcs MOQ
Price :
Negotiable Price
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
1000 tons/month
Delivery Time :
10-15DAYS
Packaging Details :
Carton Box or Pallet
Application :
Industrial Furnaces,Heat Insulation,Roof,thermal insulation,refractory
Refractoriness :
1050-1800C
Size :
Customizable
Package :
bag or carton box or pallet
Shape :
Customizable
Color :
White
Type :
blanket board module paper textile
Description
1260°C 1430°C High Temperature Ceramic Fiber Modules For Industrial Furnaces

Leadsun ceramic fiber modules deliver the highest thermal insulation efficiency available in ceramic fiber products. Each module is manufactured from a continuous folded ceramic fiber blanket, compressed to form a dense and resilient insulation unit.

The layered blanket structure ensures excellent thermal performance and uniform insulation. Ceramic fiber module linings effectively minimize heat loss, resulting in higher furnace productivity, improved energy efficiency, and reduced maintenance costs.

Ceramic fiber module physical and chemical performance index
SUNWOOL Ceramic Fiber Module
Items Common Standard High Pour High Alumina Zirconium
AL2O3(%) 44 46 47-49 52-55 39-40
Al2O3+SiO2(%) 96 97 99 99 -
ZrO2(%) - - - - 15-17
Fe2O3(%) ＜1 ＜1 ＜1 0.2 0.2
Na2O+K2O(%) ≤0.5 ≤0.5 0.2 0.2 0.2
Classification Temperature(℃) 1050 1260 1260 1360 1430
Working Temperature (℃) <1000 1000 1100 1200 1350
Density(kg/m3) 200±15 220±15 220±15 220±15 300±15
Size 300*300*200mm, 300*300*250mm, 300*300*300mm,with the anchoring piece Other sizes and shapes on request
Features

  • Fast and easy installation, reducing labor time and downtime

  • Low heat storage, helping to lower fuel consumption and operating costs

  • Lightweight lining design, requiring less steel support structure

  • Multiple anchoring systems available, suitable for different furnace designs

Applications
Ceramic Industry

  • Low-mass kiln car insulation systems

  • Thermal insulation for continuous and batch kilns

  • Kiln and furnace door linings

  • Glazing and porcelain furnace linings

Power Generation Industry

  • Duct lining insulation

  • Heat recovery steam systems (HRSG) insulation

  • Boiler insulation

  • Stack and chimney linings
