Specifications
Model Number :
Glasswool Pipe
Size :
customizable
MOQ :
100 m
Delivery Time :
10 days
Blanket density :
10-48kg/m3
Packaging Details :
100000 m/month
Payment Terms :
L/C,D/P,T/T,Western Union
Blanket Thickness :
25-200mm
Certification :
ISO CE
Package :
vacuum plastic bag
Brand Name :
SUNWOOL
Refractoriness :
650C
Place of Origin :
CHINA
Type :
board,pipe ,blanket
Price :
Negotiable
Blanket Width :
1200mm
Supply Ability :
100000 m/month
Description

Product Introduction

Glass wool insulation pipe is fabricated from molten glass spun into fine fibers. It offers excellent heat preservation, sound absorption and fireproof performance. This flexible insulation tube effectively prevents heat loss and condensation for industrial piping, air conditioning and heating systems. Options with aluminum foil facing help block moisture and vapor.

Aluminum Foil Faced Glass Wool Insulation Pipe, Heat Preservation Glass Wool Tube for HVAC

Product Specifications

Item

Specification

Material

Glass Wool (Glass Fiber)

Density

48~96 kg/m³ (Customizable)

Thermal Conductivity

≤0.043 W/(m·K) at 25℃

Working Temperature

-120℃ ~ +450℃

Fire Performance

Non-combustible, Class A1

Sound Absorption

Good sound absorption

Standard Inner Diameter

18mm ~ 1220mm (Custom sizes available)

Thickness

20mm ~ 100mm

Length

1000mm / 1200mm

Surface Facing

Plain / Aluminum Foil Faced (Alu foil vapor barrier)

Feature

Low thermal conductivity, lightweight, anti-condensation, corrosion-resistant, easy cutting & installation

Application

Thermal insulation & sound absorption for steam pipes, HVAC, chemical, power, and building piping systems

Product Features

Cylindrical prefabricated pipe sections with clean-cut edges for a snug fit around pipes

Reinforced aluminum foil protective layer: waterproof, impact-resistant, and minimizes heat loss

Easy installation: simply slip over the pipe and secure with fasteners

2. Key Specifications

Inner Diameter: 22–630 mm (compatible with various pipe types)

Thickness: 20–100 mm

Density: 48–96 kg/m³

Length: Standard 1 m

3. Applications

Insulation for central air conditioning chilled water and hot water pipes

Building heating pipes and industrial low-temperature piping

Anti-freeze and anti-condensation protection for water supply and drainage pipes

Insulation and sound absorption for piping systems in heat exchange stations and pump rooms

5. Brief Comparison: Glass Wool vs. Rock Wool

Glass Wool: Lighter, softer, and offers superior sound absorption; commonly used in buildings, HVAC systems, and low-temperature piping

Rock Wool: Higher density and superior high-temperature resistance; commonly used for exterior wall fireproofing, high-temperature equipment, and industrial kilns/furnaces
