Premium LSR Injection Equipment Customizable For Cosmetic Silicone Products

Typical Features and Options:

1,LSR Injection Unit (Special barrel and LSR screw with static seal)

2,Closed loop liquid barrel cooling

3,Pin-type shut-off nozzle (Pneumatic or hydraulic actuation)

4,LSR nozzle tip with static seal

5,LSR tip assembly and non-return valve (Optional spring-lock positive shut-off design)

6,Carriage decompression control

7,Integral mold temperature control system

8,Insulated platens

9,LSR closed loop process software package for precise volumetric control

10,Mould vacuum system (Vacuum pump, vacuum switch, interface, control software)

11,Mould sweep software and sweep device interface

12,Mould cold deck valve gate control system

13,Air blow with pressure regulation

14,Pre-dosing assembly with two component temperature controlled static mixer and purge valve

15,LSR material delivery system

THE HIGH-PRECISION (LSR) DOSING SYSTEM

1.All the parts are processed with the imported equipment with an original package to ensure the accuracy of the process parts

2.All core parts are imported from Europe or America,which ensures the stability and service life of the machine

3.Design for convenient maintenance:the displacement pump device is easy to disassemble

4.A long life service sealing element

5.Function guarantee and external valve

6.Detachable mixer

7.Material shortage and over pressure alarm safety device

8.Reproducible color adjustment

9.The coating is optimized through a special material barrel supporting disk

10.Material barrel emptying alarm

11.Provide users with special options for special actual needs

12.Comply with international and European standards

13. 200-liter barrel can be changed to a 20-liter barrel

14.The hard metal ball valve and high-speed steel piston rod with higher durability can be used for liquid materials with different viscosity

15.Mixing section that can be cooled

16.Colorant and adding and metering device

17.Feeding pump can work continously under material assistance

18.Pressure gauge display in mixed materials

Characteristics

1) Compared with the solid rubber molding, the liquid silica gel injection molding does not need the operation procedures such as molding, mixing, pre molding, etc., which saves manpower, material resources and energy, reduces equipment investment and floor space.

2) The injection molding of liquid silica gel can realize the automatic processing under the fully closed condition, eliminate the manual operation deviation, reduce the influence and pollution of various variable factors in the processing, and ensure the dimensional accuracy and internal quality of the product, which is conducive to the application of liquid silica gel in medical treatment.

3) Because the viscosity of liquid silica gel is very low (generally in the range of 10-1000pas), and its fluidity and processability are good, its injection pressure is much lower than that of solid rubber and plastic. Generally, the injection pressure is 20MPa, which can be lower than 1MPa in some cases. Therefore, it can produce products without flash, reduce material waste, and reduce the wear of equipment and mold. In addition, due to the good fluidity of liquid silica gel, it is especially suitable for forming large-scale products, extremely complex shape products or ultra-thin products, such as ultra-thin products with a forming thickness of 0.5mm and a length of 100mm, which is difficult for solid rubber materials to form.

4) The curing rate of liquid silica gel is very fast. During injection molding, the curing reaction can be completed in the range of 160-220 seconds to several minutes, so the molding cycle is short and the production efficiency is high.

5) The back pressure required for liquid silica gel in screw metering is very small, generally less than 1.5MPa. For some liquid silica gel materials with very low viscosity, even no back pressure can be set, which is mainly due to the good fluidity of low viscosity silica gel and the low gas content in liquid silica gel in normal operation. On the contrary, the large back pressure will increase the density of the unvulcanized silica gel and destroy the accurate measurement effect of the metering device.

6) Liquid silica gel does not shrink in the process of injection molding, but due to its high thermal expansion coefficient, it usually shrinks by 2% ~ 3% after demoulding and cooling. The exact shrinkage data depends on the material formula. From the point of view of processing, designers should consider some factors affecting shrinkage in advance.
