Liquid Silicone Folding Cup Fully Automatic LSR Injection Moulding Machine Vertical
Liquid Silicone Folding Cup Fully Automatic LSR Injection Moulding Machine Vertical
Liquid Silicone Folding Cup Fully Automatic LSR Injection Moulding Machine Vertical
Liquid Silicone Folding Cup Fully Automatic LSR Injection Moulding Machine Vertical
Specifications
Brand Name :
Better
Model Number :
Better-1200SD
Certification :
CE、ISO
Place of Origin :
GuangZhou，China
MOQ :
1 SET
Price :
USD42000-USD82000per set
Payment Terms :
D/P,T/T,D/A,L/C
Supply Ability :
20 sets per month
Delivery Time :
45 days
Packaging Details :
Plastic packaging
Country Of Origin :
China
Plastic Type :
Liquid Silicone
Gross Weight :
6ton-11ton
Vertical :
Vertical LSR injection molding machine
Type :
Vertical
Voltage :
220V
Control System :
PLC
Description
Liquid Silicone Folding Cup Production Equipment Fully Automatic Vertical Liquid Silicone Injection Molding Machine
Product Attributes
Attribute Value
Country Of Origin China
Plastic Type Liquid Silicone
Gross Weight 6ton-11ton
Vertical Vertical LSR injection molding machine
Type Vertical
Voltage 220V
Control System PLC
Product Description

S-guangyu provides integrated solutions including machinery, molds, and support services for manufacturing medical parts:

  • Independent double-cylinder injection system ensures injection stability and allows different glue types
  • Independent direct pressure clamping unit accommodates various mold thicknesses
  • Mechanical positioning device guarantees accurate positioning and mold protection
  • Flexible independent system design enables single-mode production
  • Wide range of technical options available

Vertical Double Slides Table LSR Injection Molding Machine with CE and ISO certification is ideal for medical silicone products and electronic silicone seals. Features include:

  • Direct pressure mold opening/closing system with horizontal injection structure
  • Faster mold adjustment and precise position control
  • Optimized for automatic part removal from mold
  • Advanced sliding rail structure reduces oil pollution and improves stability
  • Active pin valve-pattern nozzle sealing system for precise injection
  • Supports multi-station production requirements
  • High-performance servo motor system for accuracy and energy efficiency
Technical Specifications
Specification Value
Clamping Force 160tons
Size 1500*730mm
Max Mold Size 720*660mm
Min Mold Height 300+50mm
Mold Stroke 300mm
Max Daylight 600+50mm
Ejector Force 4tons
Thimble Diameter Φ25
Ejector Distance (Product) 130(100)mm
Max Hydraulic Pressure 140kg/cm²
Cooling Water 1500-1800liters/hr
Heater Power 4kw
Motor Power 22kw
Dimension (L*W*H) 2.86*2.76*3.30m
Weight 9.6tons
Liquid Silicone Folding Cup Fully Automatic LSR Injection Moulding Machine Vertical
