Specifications
Brand Name :
OUCO
Model Number :
OC-130UV
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
OUCO 130T Factory Price Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding Machine
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

OUCO 130T Factory Price Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding Machine

In OUCO, we insist on providing customers with competitive prices to ensure that you obtain excellent injection molding machines at more favorable prices and achieve higher cost-effectiveness. We provide professional recommendations for machine selection, as well as screw and barrel selection, in response to the different plastic product requirements raised by customers in different industries. We firmly believe that a deep understanding and meeting the needs of customers is the cornerstone of providing satisfactory products and services. Let's work together to create a better future!

Product Advantages

OC-130UV servo system has excellent control capabilities, which can accurately adjust the pressure, speed and position of the machine, ensuring extremely high repeatability of the injection position and achieving precise molding results. The nozzle and barrel are heated synchronously, effectively avoiding plastic carbonization and further improving the quality of the product. The injection molding machine adopts a unique dual cylinder injection system, which is fast and stable, reducing the deformation of the fixed template. In addition, the optimized design of screw components significantly enhances the plasticizing ability and effect, ensuring the smooth progress of your production process.

MODEL OC130UV
Clamping force (kN) 1300
Space between tie bar (mm*mm) 410*410
Max. mold thickness (mm) 450
Min. mold thickness(mm) 160
Opening stroke (mm) 380
Ejector stroke(mm) 120
Ejector force forward(Kn) 42
Screw diameter(mm) 45
Screw L/D ratio 18.5
Theoretical injection volume (cm3) 302
Shot weight (PS) g 274
Injection pressure(MPa) 138
Screw speed (rpm) 0-180
Dry-cycle time(g/s) 1.3
Motor power (Kw) 18.5
Oil tank capacity(L) 200
Heater power (Kw) 7.7
Machine Weight (Ton) 4
Machine size L×W×H (m) 4.6*1.2*1.8

Detail Pictures
OUCO 130T Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding Machine
OUCO 130T Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding Machine
OUCO 130T Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding MachineOUCO 130T Hydraulic Servo Lightweight And Breathable Plastic Flower Pot Injection Molding Machine
