Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Powerful low noise pneumatic tools / air leg rock drill for metallurgy 668mm YT28
Specifications
Brand Name :
KAISHAN
Model Number :
YT28
Certification :
ISO9001-2008
Place of Origin :
ZHEJAING China
MOQ :
2
Delivery Time :
7days after receive the downpayments
Packaging Details :
wooden package
color :
silver
working way :
hand held
drilling bit :
36/38/40/42
weight :
28kg
Description

Pneumatic Tools YT28 air leg Rock Drill 668 mm 28kg Kaishan famous brand factory offer

Manual drilling tools YT28 in factory prices

Place of Origin:

ZHEJIANG QUZHOU CHINA

Brand Name:

KAISHAN

Model Number:

YT28

Certification:

ISO9001

Minimum Order Quantity:

1

Price:

Packaging Details:

CARTON

Delivery Time:

7DAYS AFTER GOT THE 30%DOWNPAYMENT

Payment Terms:

FOB,CIF,LC AND SO ON

Supply Ability:

1500SETS PER MONTH

4. Specifications:

Quick Detail:

Type

YT28

Weight(kg)

26

Air consumption(L/s)

≤81

Bore Dia. (mm)

Φ34-42

Drilling depth(m)

5

Shank(mm)

22×108

Air pressure(MPa)

0.63

Suitable air-legs

FT160BC

FT160BD

Eeight(kg)

16.9

14.4

Length(mm)

1800

1400

Feed length (mm)

1365

965



Description:
This product is widely used in metallurgy, coal industry, road construction, mining and other drilling

operations.

· Hand-hold rock drill, hand hammer drilllow weight,reasonable structure,handy use and little air

consumption.

· 6 hand-hold rock drill is a tool for the secondary blasting in quarry and especailly for rocking 20mm

hose in marble and granite,it has characteristic of low weight,reasonable structure,handy use and

little air consumption


Competitive Advantage:

1). save energy and high efficiency
2). strong impact energy
3). low vibration
4). easy handling
5). low noise
6). wet drilling
7). easy cleaning air /water holes
8). spare parts easily purchasing

Specifications:

jack hammer

Model

YO18

Y18P

Y19A

YO20

Y26

Weight(kg)

18

18

19

20

26

Length(mm)

550

550

600

561

650

Cylinder size*trip(mm)

58*45

58*45

65*54

63*55

65*70

Working pressure(Mpa)

0.35-0.63

Impact frequency(Hz)

≥32

≥30

≥28

≥33

≥23

Impact energy(J)

≥22

≥22

≥28

≥26

≥30

Air consumption(m3/min)

≤20

≤24

≤37

≤33

≤47



ROCK DRILL
DRILL RIG
JACK HARMMER
