Low Voltage Cable with Copper Conductor PVC Sheathed Non-Armoured for Reliable Power Transmission
Low Voltage Cable with Copper Conductor PVC Sheathed Non-Armoured for Reliable Power Transmission
Specifications
Brand Name :
LV Low Voltage Cable
Model Number :
Low Voltage
Certification :
ISO,CCC,TUV,CE,VDE
Place of Origin :
Hebei，China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
10work days
Packaging Details :
Steel Wooden Drum
Insulation Material :
XLPE
Application :
Construction
Conductor Material :
Copper
Sheath :
PVC
Cores :
4core
Armour :
Unarmoured
Description

XLPE Insulated Low Voltage Cable Copper Conductor PVC Sheathed Non-Armoured


Application

Machinery & Equipment Wiring – Reliable power transmission for motors, pumps, and control systems.

Temporary Power Supply – Events, construction sites, and portable installations (where mechanical protection is not critical).

XLPE Insulation – Higher thermal resistance (up to 90°C) compared to standard PVC cables.

PVC Sheath – Moisture, abrasion, and chemical resistance for indoor/outdoor use.
Copper Conductor – Excellent conductivity, flexibility, and corrosion resistance.
Non-Armoured (Unarmoured) – Lightweight, cost-effective, and easy to install in conduits, trays, or ducts.


Standard


IEC 60502-1 / BS 5467 / VDE 0276-603 (for XLPE-insulated LV cables).

Suitable for dry, damp, and moderately harsh environments (not recommended for direct burial without additional protection).


Construction

Conductors:plain solid annealed copper

Insulation:Cross-linked Polyethelene (XLPE)

Outer Sheath:Polyvinyl chloride (PVC) or Low Smoke Zero Halogen (LSZH)


Parameter

No. of cores and nominal cross section Thickness of Insulation Thickness of Sheath Approx. overall Diameter Approx. weight Max. DC resistance of conductor(20℃) Current carrying capacity
(mm2) (mm) (mm) (mm) (kg/km) (Ω/km) In Air(A) In Ground(A)
4X1.5 0.7 1.8 12.6 160 12.1 21 30
4X2.5 0.7 1.8 13.6 210 7.41 28 39
4X4 0.7 1.8 14.8 280 4.61 37 51
4X6 0.7 1.8 16.0 380 3.08 47 64
4X10 0.7 1.8 18.6 530 1.83 65 86
4X16 0.7 1.8 21.0 800 1.15 84 110
4X25 0.9 1.8 24.9 1240 0.727 110 140
4X35 0.9 1.8 28.3 1600 0.524 135 170
4X50 1.0 1.8 28.4 2000 0.387 170 205
4X70 1.1 2.0 33.1 2800 0.268 215 250
4X95 1.1 2.1 37.1 4000 0.193 265 300
4X120 1.2 2.2 40.8 5000 0.153 310 345
4X150 1.4 2.4 45.2 6100 0.124 350 385
4X185 1.6 2.6 52.1 7600 0.0991 405 435
4X240 1.7 2.8 57.8 9500 0.0754 480 500
4X300 1.8 3.0 63.5 12000 0.0601 555 565
4X400 2.0 3.3 70.9 16000 0.0470 640 640


Services Offered

1.Custom Cable Production

2.OEM/ODM Services

3.Testing & Certification

4.Technical Support & Consulting

5.Logistics & Packaging

6.After-Sales Services

7.Sustainable Solutions


About Us

Low Voltage Cable with Copper Conductor PVC Sheathed Non-Armoured for Reliable Power Transmission

Projects


Low Voltage Cable with Copper Conductor PVC Sheathed Non-Armoured for Reliable Power Transmission


Package

Low Voltage Cable with Copper Conductor PVC Sheathed Non-Armoured for Reliable Power Transmission

FAQ


Q: What types of cable products does your company primarily manufacture?
A: We specialize in the production of various types of power cables, control cables, communication cables, and specialty cables, including but not limited to PVC-insulated cables, XLPE power cables, mining cables, marine cables, and photovoltaic cables.
Q: Which international standards do yourproducts comply with?
A: Our products comply with various international standards, such as IEC, BS, UL, ASTM, GB, etc., depending on the product type. We can provide products compliant with different international standards.
Q: What quality certifications do you hold?
A4: We have obtained ISO and CCC quality management system certifications, and some products have also obtained
international. We can also apply for specific certifications based on customer requirements.
Q: What is the delivery lead time?
A: Standard products are typically in stock and can be shipped within 7-15 days. Customized products require 15-45 days depending on quantity.
Q: Do you accept customized products?
A: We provide OEM and ODM service, we can customize cable products according to customer's special requirements, including specifications, colors, packaging and so on.
