Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection
Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection
Specifications
Brand Name :
Low Voltage Cable
Certification :
IEC,CE,ISO,TUV
Place of Origin :
Hebei，China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
,L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
7-30 days based on different qty
Packaging Details :
Rolls, Wooden Drums, Steel Drums, Reels or customized
Voltage :
0.6/1kV
Insulation :
PVC
Jacket :
PVC
Feature :
LSZH
Application :
FIame Retardant
No of Core :
4-1
Description

Flame Retardant Low Voltage Power Cable 0.6/1Kv Pvc Insulated for Electrical Connection



Application



The cables are specifically designed to enhance fire safety while maintaining the versatility of standard PVC cables, they are widely used in environments where fire resistance, reduced flame propagation, and minimal smoke emission are critical.



Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical ConnectionFlame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical ConnectionFlame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection



Construction


  1. Conductor: Circular, solid, compacted or sector shaped stranded Copper or aluminum
  2. Insulation: PVC
  3. Filler: non-hygroscopic material
  4. Binder tape: non-hygroscopic material
  5. Sheath: PVC


Characteristics


  1. Test Voltage: 3.5kV 5min No Breakdown
  2. The ambient temperature for installation: ≥0℃.
  3. Maximum conductor temperature in normal operation:≤90℃.
  4. Max operating temperature of con. When cable short-circuited(5s maximum duration): 250℃.
  5. Permissible minimum bending radius:
  6. Single unarmoured cable: 20 x OD
  7. Multi-core unarmoured cable: 15 x OD
  8. Single armoured cable: 5 x OD
  9. Multi-core armoured cable: 12 x OD
  10. Note : OD=Overall Diameter of Cable



Specification


Specs

mm²

Conductor diameter
mm

Nominal thickness of insulation
mm

Nominal thickness of sheath
mm

Approximate outer diameter of cable
mm

Approximate cable weight
kg/km

4×2.5+1×1.5

1.78/1.38

0.7/0.7

1.8

12.9

248

4×4+1×2.5

2.25/1.78

0.7/0.7

1.8

14.1

332

4×6+1×4

2.76/2.25

0.7/0.7

1.8

15.4

440

4×10+1×6

4.0/2.76

0.7/0.7

1.8

18.4

635

4×16+1×10

5.0/4.0

0.7/0.7

1.8

21.2

930

4×25+1×16

6.1/5.0

0.9/0.7

1.8

25.2

1417

4×35+1×16

7.2/5.0

0.9/0.7

1.8

27.7

1813

4×50+1×25

8.4/6.1

1.0/0.9

1.9

31.7

2438

4×70+1×35

10.0/7.2

1.1/0.9

2.1

36.7

3432

4×95+1×50

12.0/8.4

1.1/1.0

2.2

42.0

4641

4×120+1×70

13.0/10.0

1.2/1.1

2.4

45.9

5867

4×150+1×70

14.9/10.0

1.4/1.1

2.5

51.3

7092

4×185+1×95

16.5/12.0

1.6/1.1

2.7

57.1

8891

4×240+1×120

18.4/13.5

1.7/1.2

2.9

63.0

11473

4×300+1×150

21.0/14.9

1.8/1.4

3.1

70.5

14294

4×400+1×185

23.4/16.5

2.0/1.6

3.4

78.3

18208


Contact US for more information


PPLICATION


Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection


ABOUT US


Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection


PROJRCTS


Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection


PARTNER


Flame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical ConnectionFlame Retardant Low Voltage Power Cable 0.6KV 1KV PVC Insulated For Electrical Connection


FAQ

What are the key flame retardant standards for these cables?‌
Cables comply with IEC 60332-1-2 for flame spread resistance and IEC 61034 for smoke density testing

‌What is the minimum operating temperature for PVC insulation?‌
PVC insulation maintains performance from -15°C to +70°C.

Can these cables be used in conduit systems?‌
Yes, they are rated for installation in conduits, ducts, or trays.

‌What voltage rating is suitable for building wiring?‌
The 0.6/1KV rating is ideal for low-voltage applications like lighting and power distribution.

‌Are there color-coding options for phase identification?‌
Standard colors include black/red/blue for phases and green/yellow for earth.

‌What is the maximum conductor temperature during operation?‌
PVC-insulated conductors withstand up to 90°C under short-circuit conditions.

‌Do these cables require special termination accessories?‌
Standard PVC cable glands and connectors are compatible.

‌Are these cables suitable for outdoor use?‌
UV-resistant PVC jackets are available for outdoor applications.

‌What certifications should I look for?‌
Look for CE marking, CPR compliance, and IEC 60502 certification.
