Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Black PTFE Coated Fiberglass Fabric with High Break Down Voltage and Heat Resistant Properties
Specifications
Unit Weight :
17 Oz/sqy
Elongation At Break :
200%-320%
Coating Side :
1 Or 2
Colour :
Black
Product Namee :
Silicone Baking Mat
Good Features :
Heat Resistant
Break Down Voltage :
10KV/mm
Keywords :
High Temperature Resistant
Brand Name :
3A Rubber
Model Number :
3A3009
Place of Origin :
China
Certification :
ISO9001
MOQ :
1roll
Packaging Details :
Packing in rolls and cartons, Pallets
Delivery Time :
7-15days
Payment Terms :
Bank T/T,L/C,D/P,Paypal,Western Union,Wechat,Alipay
Supply Ability :
100000m/month
Description
Black PTFE Coated Fiberglass Sheet
High breakdown voltage heat resistant PTFE coated fiberglass fabric, also known as PTFE coated glass cloth, is a highly durable and flexible material widely used across various industries.
Product Overview
PTFE coated glass fiber cloth offers exceptional heat and high temperature resistance, making it essential for demanding applications in multiple sectors.
Key Attributes
Joint Types Bull Nose Joint, Alligator Joint
Density 2.1-2.3g/cm³
Temperature Resistance -180°C to +260°C
Elongation at Break 200%-320%
Breakdown Voltage 10KV/mm
Key Features
  • Exceptional heat resistance suitable for high temperature environments
  • Withstands extreme temperatures from -180°C to +260°C without property loss
  • Durable and long-lasting under harsh conditions
  • Flexible and easy to shape for various applications
  • Non-stick, food grade surface
  • High breakdown voltage electrical insulation
Applications
PTFE coated fiberglass fabric serves a wide range of industries including:
  • Food processing and packaging
  • Chemical processing
  • Automotive manufacturing
  • Aerospace applications
  • Electronics and electrical insulation
  • Industrial conveyor belts and release sheets
  • Construction materials and anti-corrosion coatings
  • Baking and cooking surfaces
Technical Specifications
Property Value
Material PTFE coated fiberglass fabric
Temperature Range -70°C to 260°C
Thickness 0.08mm-0.30mm
Width 1000mm, 1270mm, 1550mm, or customized
Length 10m, 20m, 30m, or customized
Tensile Strength ≥ 350N/cm
Flame Resistance Yes
Chemical Resistance Excellent
Food Contact Safe Yes
Customization & Ordering
3A Rubber offers comprehensive customization services for PTFE coated fiberglass fabric:
Brand Name 3A Rubber
Model Number 3A3009
Certification ISO9001
Minimum Order 1 roll
Delivery Time 7-15 days
Supply Capacity 100,000m/month
Packaging & Shipping
Fabric is packaged in rolls wound around cardboard or plastic tubes, wrapped in plastic or cardboard boxes for protection. Standard ground shipping via UPS, FedEx, or DHL available, with freight options for bulk orders.
Contact Information
Phone: +86-755-28829555
Email: sales@3arubber.com
Website: www.3arubber.com
