Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
Specifications
Color :
dark red
Working tempature :
maximum 260°C
Width :
1.25-1.50m
Brand Name :
3A Rubber
Model Number :
3A3008
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
1roll
Price :
negotiation
Payment Terms :
T/T,L/C,Paypal,Western Union
Supply Ability :
10000rolls per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Packed in rolls
Length :
20-100m
Material :
silicone+glassfiber+silicone
Thickness :
0.25-0.8mm
Description
Anti-Water PTFE Coated Fiberglass Fabric Sheet, Flame Resistant Fabric
High Temperature Single Side Silicone Coated Fiberglass Fabric and Cloth
Silicone coated fabric is a multifunctional thermal insulation material with high performance. Due to its properties of chemical stability, high temperature resistance and ablation resistance, it's widely used in fireproof industry (making fireproof protective cloth, fireproof curtain, welding blanket), thermal insulation and anticorrosion for pipes.
Key Properties
  • Superb electric insulation
  • Good heat and cold resistance
  • Excellent sealing properties
  • Inert to majority of chemical reagents
  • Water repellent and oil repellent
  • Soft and pliable, easy to tailor with good processing performance
  • Working temperature can be increased up to 1000°C with high silica fiberglass fabric substrate
Manufacturer Information
TYCM is one of the specialized manufacturers of silica fiberglass in China with proprietary technology processes. Our products are sold widely to many large state-owned industrial enterprises in China and exported internationally. TYCM provides one-sided/double-sided silicone coated fiberglass fabric with various coating weights and colors for different applications.
Technical Specifications
ITEM STANDARD TEST DATA
PRODUCT CODE DRS-46 DRS-46
BASE FABRIC HS-1100 HS-1100
WIDTH, CM 92±1 92.00
WEAVE STYLE Satin 12HS Satin 12HS
WARP COUNTS, ends/cm ≥18 21.11
FILL COUNTS, ends/cm ≥13 15.05
MD BRK STRN, N/inch ≥ 1000 1021
CD BRK STRN, N/inch ≥ 750 793
WEIGHT, G/M² 1400±20 1389
STD ROLL, Y/roll 50.0 50.0
THICKNESS, mm 1.3 ± 0.05 1.4
SILICA CONTENT % ≥ 96 97.04
LINEAR SHRINKAGE % 5-10 6.1
L.O.I % 7-12 8.4
WORKING TEMPERATURE 1000 ℃ 1000 ℃
SILICON WEIGHT, warp side 300G/M² 300G/M²
COLOR DER, GREY... DER, GREY...
Flame Resistant Water Repellent PTFE Coated Fiberglass Fabric with High Temperature Resistance
