Specifications
Brand Name :
E-link
Model Number :
LNK-100G-SOA1310
Certification :
ISO9001, CE, FCC, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
100000PCS/Month
Delivery Time :
7-10 working days
Packaging Details :
Industrial PoE Switch Standard Carton Packaging
Working temperature :
20°C～60°C
Weight :
240g
L×W×H :
100mm×69mm×22mm
Material :
Iron (Shell)
Color :
Black
Warranty :
5 years
Description

LNK-SE001 1Port RS-232/RS-485/RS-422 to Ethernet Serial Server (10/100M)

Product Advantages

Ø 1. 3-in-1 RS-232/RS-485/RS-422 serial interface

Ø 2. Support 10/100M auto-sensing Ethernet

Ø 3. Support 300bps～115.2Kbps

Ø 4. Support TCP, UDP, ARP, ICMP, HTTP and DHCP protocol

Ø 5. Support across gateway, router communication

Ø 6. Support standard TCP/IP SOCKET

Ø 7. Support Virtual serial driver access and auto connect after the network disconnect

Ø 8. Provide bath installation Windows configure tool

Ø 9. Choice of configuration methods: Windows, TELNET and WEB

Overview

LNK-SE001 is a serial device server which can connect with network fast. it provides one RS-232/485/422 (RS-232: DB9M; RS-484/422: 4 bits terminal block) and 1 10/100Base-T(X) Ethernet port, it can manage the disperse serial device or host computer by network, easily and convenience. setting or software upgrade by serial program group in apply, support TCP, UDP, ARP, ICM and DHCP protocol, support Windows Native COM and auto-connect function once the network intermit.

Technical Indexes

Parameter

Specifications

Ethernet

Standard:10/100Base-T(x)

Speed:10/100M auto-sensing

Working: TCP Server, TCP Client, UDP and Real COM driver

Memory: Most 32Kbyte

Transmission: 100m

Electromagnetism isolate: 1KV

Connector: RJ45

Serial

Standard: RS-232/RS-485/RS-422

Signals: RS-232:DCD,RXD,TXD,DTR,GND,DSR,RTS,CTS

RS-485:Data+,Data-,GND

RS-422:TXD+,TXD-,RXD+,RXD-,GND

Working mode: Asynchronous format, point to point, 2 wires half duplex, 4 wires full duplex

Parity: None, Even, Odd, Space, Mark

Data bits: 7bit, 8bit

Baud rate: 300bps ~ 115.2Kbps

Flow control: RTS/CTS

Direction control: RS485 side adopt ADDC technology, auto text and control data transfer direction

Loading: RS-485/422 side support 32 nodes (customize 128 nodes) loopback

Transmission: RS-485/422 side 1200M,

RS-232 port 15M

Interface protection:1500W surge protection,

15KV ESD protection

Power

Power input: 12~36VDC

Consumption: <1W

Environment

Working temperature:-20°C～60°C

Storage temperature:-25°C～85°C

Humidity: Relative humidity 5% to 95%

Appearance

Color: Black

L×W×H: 100mm×69mm×22mm

Material: Iron (Shell)

Weight: 240g

Warranty

5 years

Approvals

FCC, CE, RoHS approvals
