7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel
Specifications
Brand Name :
AUO LCD Panel
Model Number :
CLAA040JC06CW
Certification :
ISO9001
Place of Origin :
Japan,Korea
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size :
7.0 inch
Resolution :
800(RGB)×480 , WVGA
Display Mode :
TN, Normally White, Transmissive
Outline :
170.8×107.95×21.5 mm
Surface :
Antiglare (Haze 40%), Hard coating (3H)
Brightness :
350 cd/m² (Min.)
Viewing Angle :
60/60/40/60 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type :
4S4P WLED
Description

7.0 inch 152.4*91.44 mm Normally White CLAA040JC06CW for Automotive Display panel

Why Choose US:

1. Prompt reply within 12 hours.

2. Understand inquiry in any language.

3. Products with top quality.

4. Very competitive prices.

5. 6-year experience inindustrial LCD Screen replacements.

6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.

7. Fabulous after-sale service.

AUO C070VW02 V1 General Features

Panel Brand : AUO
Panel Model : C070VW02 V1
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 7.0 inch
Resolution : 800(RGB)×480 , WVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 152.4×91.44 mm
Outline : 170.8×107.95×21.5 mm
Surface : Antiglare (Haze 40%), Hard coating (3H)
Brightness : 350 cd/m² (Min.)
Contrast Ratio : 300:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 20/30 (Max.)(Tr/Td)
Viewing Angle : 60/60/40/60 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type : 4S4P WLED
Signal Interface : TTL (1 ch, 6-bit) , 98 pins
Input Voltage : 3.3/9.8/15/-7V (Typ.)(VDD/AVDD/VGH/VGL)

Excellent service on before-sale, on-sale and after-sale

1. We provide one year warranty, will provide the after-sale service for you if any quality problems.

2. Your inquiry related to our products or prices will be replied in 24 hours.

3. We will track the shipping status time by time so that buyer can receive our goods in time and safely.

AUO C070VW02 V1 Mechanical Features

Panel Size : 7.0 inch
Dot Resolution : 800(RGB)×480 (WVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 133 PPI
Aspect Ratio : 15:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0635×0.1905 mm (H×V)
Pixel Pitch : 0.1905×0.1905 mm (H×V)
Weight : 300±30g
Surface : Antiglare (Haze 40%), Hard coating (3H)
Active Area : 152.4×91.44 mm (H×V)
Bezel Area : 153.6×92.64 mm (H×V)
Outline Dimension : 170.8×107.95 mm (H×V)
Outline Depth : 11.7/21.5 (Typ./Max.) mm
Holes & Brackets : Side mount holes (4-Φ4) on left, right slugs
Landscape or Portrait : Landscape type
Touch Panel : Embeded (4-wire Resistive)

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LH550WF3-SH01 LG Display 5.5" 1080×1920
LC320DXY-SHA3 LG Display 31.5" 1366×768
LC490EQL-SHA2 LG Display 49" 3840×2160
LC430EQL-SHA2 LG Display 43" 3840×2160
LC430DUY-SHA2 LG Display 43" 1920×1080
LC550EGY-SHM2 LG Display 55" 3840×2160
LC320DXJ-SFA9 LG Display 31.5" 1366×768
LH400WV3-SD06 LG Display 4.0" 480×800

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

Details Pictures for CLAA040JC06CW LCD Screen Replacements
