Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction
Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction
Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction
Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction
Specifications
Measure principle :
Polymer films, alumina capacitors, phosphorus pentoxide method(op)
Environmental temperature :
-25°C ~ +55°C
Overall machine weight :
About 8 kg
Model Number :
RL-U300
Place of Origin :
Xi'an, Shaanxi, China
Supply Ability :
Supply Ability: ＞10000 Sets Per Year
Target Gas :
All Gas
Price :
Negotiable
Alarm Mode :
Sound
Payment Terms :
L/C、D/A、D/P、T/T
type :
Multi-Gas Detector
material :
Metal
Precision :
≤±1.5℃ (above -60℃), ≤±2℃ (below -60℃)
Overall dimensions :
482mm (width) x 370mm (depth) x 136mm (height)
Brand Name :
Runlai
Packaging Details :
Export Standard
Accuracy Class :
High Accuracy
Delivery Time :
appointed time
Certification :
ISO certification
customized support :
OEM/ODM/OBM/Software Reengineering
Operating voltage (customizable) :
220-240VAC, 50\60Hz
Measuring range :
-100.0~0.0℃/-80.0~+20.0°C/-60.0~+60.0°C/0-1000PPM(range selectable)
Inlet pressure :
0.05 MPa ≤ Inlet pressure ≤ 0.25 MPa
MOQ :
1
Response time :
T90≤3min
Description

High Accuracy Gas Dew Point Meter Micro Water Tester Trace Water Analysis Customizable Detector Metal Construction Runlai U300

Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Product Introduction

The RL-U300 intelligent dew point analyzer is a high-performance online gas dew point measurement instrument. It utilizes advanced sensor technology to accurately and stably measure various dry or dew point values.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

This product features advanced design, intelligent operation, and powerful data management and communication capabilities. It is widely used in industries such as air separation, petrochemicals, metallurgy, power, and natural gas, providing reliable assurance for industrial process control and gas quality monitoring.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal ConstructionGas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Product Features

Intelligent Operation and User-Friendly Experience

Equipped with a fully Chinese touch operation interface, parameter settings, instrument calibration, data querying, and other operations are intuitive and convenient. The screen can simultaneously display real-time measurement values, historical data curves, and equipment status, making information clear at a glance and greatly enhancing the user's interaction experience and work efficiency.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Powerful Data and Communication Functions

It has massive data storage capacity and supports scheduled automatic storage, making it easy to trace and analyze historical data. It provides multiple standard digital and analog signal output interfaces and can be optionally equipped with Ethernet functionality, easily enabling integration with computers, control systems, and wide area networks for two-way data communication.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Outstanding and Accurate Measurement Performance

Using high-performance imported sensors combined with advanced temperature and pressure compensation technology, it effectively reduces the impact of environmental fluctuations on measurements. The instrument features fast response speed, high measurement accuracy, good repeatability, and strong long-term stability, ensuring accurate and reliable data under various operating conditions.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Reliability and High Adaptability

The entire unit is designed to be sturdy and durable with a long lifespan, suitable for harsh industrial environments. It includes a new type of gas path flow stabilization system to ensure measurement stability; at the same time, the instrument has self-checking upon startup, fault diagnosis functions, and can be optionally equipped with automatic calibration and built-in suction pumps to meet the customized application needs of different customers, ensuring long-term continuous and reliable operation.Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction

Gas Dew Point Analyzer Micro Water Tester Trace Water Analysis Detector Metal Construction
