Industrial Portable Explosion Proof Gas Dew Point Analyzer Metal Construction Micro Water Analyzer Detector
Industrial Portable Explosion Proof Gas Dew Point Analyzer Metal Construction Micro Water Analyzer Detector
Industrial Portable Explosion Proof Gas Dew Point Analyzer Metal Construction Micro Water Analyzer Detector
Industrial Portable Explosion Proof Gas Dew Point Analyzer Metal Construction Micro Water Analyzer Detector
Specifications
Target Gas :
All Gas
Alarm Mode :
Sound
Packaging Details :
Export Standard
type :
Multi-Gas Detector
Supply Ability :
Supply Ability: ＞10000 Sets Per Year
MOQ :
1
Delivery Time :
appointed time
Payment Terms :
L/C、D/A、D/P、T/T
Accuracy Class :
High Accuracy
Certification :
ISO certification
Place of Origin :
Xi'an, Shaanxi, China
Brand Name :
Runlai
Price :
Negotiable
Description

Industrial High Accuracy Portable Explosion Proof Gas Dew Point Meter Metal Construction Customizable Micro Water Analyzer Detector Runlai E300Ex

Product Specifications
Measurement principle: Imported thin-film capacitive ceramic humidity sensor;
Measurement range: -100.0 ～ +20°C -80.0 ～ +20°C -60.0 ～ +60°C (Range can be selected arbitrarily)
Accuracy: ±1°C (above -60°C) ±1.5°C (below -60°C)
Repeatability: ±0.5°C;
Stability: ±1%/7 days;
Sample gas flow rate: (2±0.5)L/min;
Response time: τ90 ≤ 3 minutes;
Sample gas pressure: 0.05MPa ≤ inlet pressure ≤ 0.25MPa
Analog output: Isolated 4 ～ 20mA standard output, load ≤ 5000Ω;
Digital output: Standard RS485, capable of two-way communication with computers;
Contact output: Dual relay output 220VAC, 10A or 24VDC, 2A;
Operating environment: Temperature: -15°C～+45°C;
Power supply: (220±22)VAC, (50±5)Hz;
Dimensions: 480mm(w)*136mm(h)*370mm(d);
Mounting dimensions: 440mm(w)*136mm(h)
Weight: Approximately 4.5Kg.
Service life: >12 months (under normal operating conditions);
Gas interface: Φ6 stainless steel pipe (can be customized according to customer requirements);
Mounting method: Embedded installation;
Key Features
  • Features high-performance embedded integrated touch, TFT true color display;
  • Can simultaneously display measurement value, historical curve, range, status, and various parameter setting interfaces;
  • Controls contact output, self-alarm for over-limit (buzzer), and control mode can be set arbitrarily, standard 4~20mA current output;
  • Ethernet port for connection to wide area network;
  • Easy component selection, can measure up to four components simultaneously, and components can be changed as required by the user;
Applications

Widely used for online detection of dew point content of various gases (such as nitrogen, oxygen, argon, hydrogen, etc.) in industries such as air separation, petrochemicals, metallurgy, electronics and power, machinery manufacturing, and others. Widely used for online detection of dew point content of various gases (such as nitrogen, oxygen, argon, hydrogen, etc.) in industries such as air separation, petrochemicals, metallurgy, electronics and power, machinery manufacturing, and others.
