Real Time Industrial Gas Analysis System Multi Gas Detector Customizable
Real Time Industrial Gas Analysis System Multi Gas Detector Customizable
Real Time Industrial Gas Analysis System Multi Gas Detector Customizable
Real Time Industrial Gas Analysis System Multi Gas Detector Customizable
Specifications
Model Number :
RL-601
Alarm Mode :
Sound
MOQ :
1
Delivery Time :
appointed time
Measure principle :
Electrochemical/Laser/Magnetic Oxygen/Infrard
Gas Inlet pressure :
0.05 MPa ≤ Inlet pressure ≤ 0.25 MPa
Certification :
ISO certification
material :
Metal
Packaging Details :
Export Standard
Environmental temperature :
-25℃~+55℃
Payment Terms :
L/C、D/A、D/P、T/T
Precision :
≤±2%F.S
Overall dimensions :
1800mm*800mm*600mm (H*W*D)
Brand Name :
Runlai
Accuracy Class :
High Accuracy
Place of Origin :
Xi'an, Shaanxi, China
customized support :
OEM/ODM/OBM/Software Reengineering
Price :
Negotiable
Measuring range :
Different gases, different ranges (pls check the details below)
Overall machine weight :
About 130 kg
Supply Ability :
Supply Ability: ＞10000 Sets Per Year
Response time :
T90≤10S
Operating voltage (customizable) :
220V±10%, 50Hz
Description
Runlai RL-601 Multi-Gas Detector CO CO2 H2 CH4 O2 CnHm Customizable High Accuracy Metal

The RL-601 Gas Calorific Value Comprehensive Analysis System employs multiple detection technologies including electrochemistry, laser, magnetic oxygen, and infrared to accurately analyze concentrations of CO, CO2, H2, CH4, O2, CnHm and other components in real-time, while automatically calculating calorific value. The system utilizes a straight-tube sampling probe for gas collection, transmitted via heated pipeline to the pre-treatment unit. The back-blow control system and optimized sample processing design ensure gas cleanliness and stability. High-precision sensors complete rapid detection, with data connectivity to central control systems for remote monitoring. Ideal for continuous monitoring in industrial applications including coke oven gas operations.

Technical Specifications
Tested Gases CO, CO2, H2, CH4, O2, CnHm (customizable)
Measuring Range CnHm: 0-1%
CO: 0-50%
CO2: 0-20%
H2: 0-5%
O2: 0-5%
CH4: 0-1%
Application Areas Blast furnaces, converters, coking ovens, gas processing, galvanizing lines, coal plants, cement plants, petrochemical facilities, calcium carbide furnaces, LNG operations, metallurgy, electronic power, environmental protection
Key Features
  • 24-Hour Real-Time Monitoring: Continuous operation with real-time monitoring of oxygen content and related parameters to ensure data accuracy and timeliness
  • High Precision Measurement: Advanced sensor technology for precise measurement of CO, CO2, H2, CH4, and O2 concentrations with automatic calorific value calculation
  • Low-Maintenance Design: Optimized sample processing system reduces maintenance frequency and failure rate while enhancing long-term operational stability
  • Smart Management: Central control system connectivity enables remote monitoring and data sharing for improved production management efficiency
  • Industrial-Grade Reliability: Designed for complex industrial environments including coke oven gas applications, meeting long-term stable monitoring requirements under harsh conditions
  • Real Time Industrial Gas Analysis System Multi Gas Detector Customizable
