Specifications
Brand Name :
EDL
Model Number :
738-86A
Certification :
ISO9001, ISO14001, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30,000pcs/day
Delivery Time :
3-15days
Packaging Details :
Carton
Name :
Heavy Duty Casters
Wheel Diameter :
8inch(200mm)
Dynamic Load :
500kg
Tread Material :
TPU
Core Material :
Aluminum
Mounting Type :
Rigid/Swivel/Brake
Mounting Height :
241mm
Tread Color :
Yellow
Frame Material :
Hot-Rolled Plate
Plate Thickness :
6mm
Bracket Thickness :
5mm
Surface Treatment :
Zinc Coating
Bracket Width :
61mm
Wheel width :
50mm
Bearing :
Double ball bearing
Applicable Temperature :
-30℃～80℃
Tread Hardness :
95A
Description

EDL Heavy Duty 8inch 500kg Plate Aluminum Caster by Rigid, Swivel and Brake type 738-86A


The EDL Heavy Duty 8-inch 500kg Plate Aluminum Caster 738-86A is built for high-load applications, delivering exceptional strength and mobility. Its large 8-inch diameter enhances maneuverability on uneven surfaces, making it perfect for industrial warehouses, logistics, and heavy-duty carts. The yellow TPU wheel offers excellent abrasion resistance, shock absorption, and floor protection, ensuring smooth and quiet operation. The aluminum alloy core provides a lightweight yet robust structure, reducing overall equipment weight while maintaining superior durability. Featuring a 6mm thick hot-rolled steel plate, this caster guarantees a strong and stable installation. Available in rigid, swivel, dual brake, wheel brake, side brake, and directional lock options, it adapts to diverse working environments. Whether used for heavy machinery, factory trolleys, or material handling, this caster ensures long-lasting performance under demanding conditions.

Wheel ltem No.Instruction

Wheel

Item No.

 Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

 Core Tread Bearing

Applicable

Temperature

 Hardness
738-86A 8" 200mm 50mm 61mm 500Kg Aluminum

TPU

Double ball

bearing 6203

 -30℃～80℃ 95A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86AHeavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

Heavy Duty Castors 200mm 8 Inch Swivel Caster With Brake 738-86A

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
