L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
Specifications
Mould Weight :
2T
Part Material :
L3AL-1201
Standard Parts Brand :
MISUMI
Part Name :
Automotive air cooler
Mould Life :
1,000,000 shots
Punch Tonnage :
200T
Mould Type :
Stage mold
Mould Size :
1000*800*450mm
Brand Name :
IDO
Model Number :
automotive air cooler
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$10000-$50000
Payment Terms :
L/C,T/T
Supply Ability :
300 sets/year
Delivery Time :
45days
Packaging Details :
Wooden Case, Anti-Rust Oil, Vacuum Packaging
Description
L3AL-1201 Sheet Metal Stamping Die for Automotive Air Cooler Components
Description:

Meet our Advanced Metal Stamping Stage Die, designed for fast, precise automotive air cooler fabrication. Built for durability and accuracy, it delivers consistent, high-quality components every time. Streamline your production, reduce waste, and boost efficiency with a die that combines speed, reliability, and precision.

Quick Detail:
  • Cycle: 6 to 14 seconds, product-dependent.
  • Quick repair within 30 minutes, rapid tool change within 15 minutes.
  • Punch edges need sharpening every 300k–500k strokes.
  • Software manages die movements.
  • Only sub-dies need dismantling during maintenance.
  • Single tool set produces several models; changeovers are program-controlled.
Specifications:
Mould/Tool Type Stage tool/mould/die
Production Application Automobile (heat shield, radiator...)
Metal Sheet Material Stainless Steel (304, 430...), PCM, VCM, SGCC, Aluminum (6061, 6063,7075...), Copper
Mould Material V8, ASP60, P20, ASSAB88, XW-42, SKD11, DC53, CR12MOV, AMPCO25
Mould Base SD, LKM Standard, HASCO Standard, Self-made, etc.
Tolerance ±0.003mm
Hardness Upon request
Surface Treatment TiCN/ Polishing/ mirror polishing/ plating/ heat treatment / Deep Cooling or according to your parts
Precision Machining CNC/ surface grinding machine/ wire cutting/ EDM
Measuring Instruments CMM/ Profile projector/ electronic height gauge/ spectrum analyzer / caliper/ microscope/ micrometer, etc.
Drawing Format DWG, STP, STEP, X_T, IGES, PDF
Design Software Auto CAD, UG, Solidworks
Trade terms FOB (Shanghai)
Mould Lead time Generally 6~8 weeks (as per actual situation)
