Current Sense Transformer BOURNS PCS020-EE0502KS for Accurate Measurement in Electronic Applications
Current Sense Transformer BOURNS PCS020-EE0502KS for Accurate Measurement in Electronic Applications
Specifications
Turns Ratio :
100:1
Rated input Current :
20A
Frequency Range :
1MHz
DCR Primary Side (Max) :
7mΩ
Description :
100:1 20A 1MHz Current Transformers RoHS
Mfr. Part # :
PCS020-EE0502KS
Model Number :
PCS020-EE0502KS
Description

Product Overview

The PCS Series Current Sense Transformers are designed for accurate current measurement in various electronic applications. Featuring surface mount technology, these transformers support frequencies up to 1 MHz and operate within a wide temperature range of -40 C to 125 C. They are RoHS compliant and suitable for use in switched-mode power supplies, motor control, overload sensing, and general AC current applications.

Product Attributes

  • Brand: Bourns
  • Compliance: RoHS compliant
  • Core Material: P4
  • Bobbin Material: PM9630
  • Wire Material: XUEW and UEWH
  • Tape Material: PI-310
  • Glue Material: S-9001
  • Clip Material: SUS301

Technical Specifications

General Specifications
Specification Value
Operating Temperature -40 C to +125 C
Isolation Between Windings (PCS020) 500 Vrms
Isolation Between Windings (PCS040) 800 Vrms
Frequency Up to 1 MHz
Moisture Sensitivity Level 1
Electrical Specifications @ 25 C
Bourns Part Number Turns Ratio (Primary : Secondary) Secondary Inductance Min. (mH) DCR () Volt-time Product on Secondary Max. (V-sec) Terminating Resistance (1 V Output at Rated Current) () Primary Ref. (m) Secondary Max. ()
PCS020-EE05081S 1 : 20 0.081 7 0.4 10.8 1 1
PCS020-EE05180S 1 : 30 0.18 7 0.87 16.2 1 1.5
PCS020-EE05320S 1 : 40 0.32 7 1.14 21.6 2 2
PCS020-EE05500S 1 : 50 0.5 7 1.5 27 2.5 2.5
PCS020-EE05730S 1 : 60 0.73 7 1.98 32.4 3 3
PCS020-EE05980S 1 : 70 0.98 7 4.75 37.8 3.5 3.5
PCS020-EE0502KS 1 : 100 2.0 7 5.5 54 5 5
PCS020-EE0503KS 1 : 125 3.0 7 7 67.5 6.25 6.25
PCS040-EF13340S 1 : 20 0.34 1 0.18 50.8 0.5 0.5
PCS040-EF13760S 1 : 30 0.76 1 0.265 76.2 0.8 0.8
PCS040-EF1301KS 1 : 40 1.36 1 0.56 101.6 1 1
PCS040-EF1302KS 1 : 50 2.12 1 0.705 127 1.3 1.3
PCS040-EF1303KS 1 : 60 3.06 1 0.85 152.4 1.5 1.5
PCS040-EF1304KS 1 : 70 4.16 1 1 177.8 1.8 1.8
PCS040-EF1305KS 1 : 80 5.44 1 1.15 203.2 2 2
PCS040-EF1308KS 1 : 100 8.5 1 1.45 254 2.5 2.5
PCS040-EF1313KS 1 : 125 13.3 1 1.85 317.5 3.1 3.1
PCS040-EF1319KS 1 : 150 19.2 1 2.25 381 3.8 3.8
PCS040-EF1334KS 1 : 200 34 1 4.06 508 5 5
Product Dimensions (mm/inches)
Model Max Length Max Width
PCS020 8.13 (.320) 6.22 (.245)
PCS040 19.91 (.784) 16.51 (.650)
Packaging Specifications
Model Quantity per Reel Reel Diameter
PCS020 1000 pcs. 13-inch
PCS040 300 pcs. 13-inch

2411220604_BOURNS-PCS020-EE0502KS_C6949286.pdf
