Model BOURNS 055664 Current Sense Transformer Suitable for Industrial and Motor Control Applications
Model BOURNS 055664 Current Sense Transformer Suitable for Industrial and Motor Control Applications
Specifications
Frequency Range :
200kHz~3MHz
DCR Primary Side (Max) :
1.8Ω
Description :
200kHz~3MHz Current Transformers RoHS
Mfr. Part # :
055664
Model Number :
055664
Description

Model 0556xx Series Current Sense Transformers

Product Overview

The Model 0556xx Series Current Sense Transformers are designed for accurate current measurement in various industrial applications. Featuring an integrated primary current path and reinforced insulation, these transformers offer a wide turns ratio range from 1:50 to 1:2500 and a rated current capability up to 40 A. They are RoHS compliant and halogen-free, making them suitable for environmentally conscious designs. Key applications include switched-mode power supplies, motor control, overload sensing, and general AC current monitoring.

Product Attributes

  • Brand: Bourns
  • Certifications: RoHS compliant, Halogen Free
  • Materials: Core - Ferrite, nanocrystalline; Wire - Enameled copper; Terminal Finish - Sn
  • Packaging: 120 pcs. per tray

Technical Specifications

Bourns Part Number Turns Ratio Frequency Range Current Rating Inductance Volt-time Product on Secondary Max. DC Resistance
055650 50:1 10-300 kHz 0.1-40 A 6 mH 180 V-s 0.140
055651 100:1 10-300 kHz 24 mH 360 V-s 0.47
055652 200:1 10-300 kHz 96 mH 715 V-s 1.8
055653 300:1 10-300 kHz 216 mH 1070 V-s 3.4
055654 400:1 10-300 kHz 384 mH 1430 V-s 5.7
055655 500:1 10-300 kHz 600 mH 1785 V-s 9.4
055656 600:1 10-300 kHz 864 mH 2140 V-s 13.5
055657 1000:1 10-300 kHz 2400 mH 3570 V-s 35
055658 1000:1 50 Hz 30 H 6.4 V-ms 25
055659 1500:1 50 Hz 67.5 H 9.5 V-ms 52
055660 2000:1 50 Hz 120 H 12.7 V-ms 100
055661 2500:1 50 Hz 187.5 H 15.9 V-ms 135
055662 50:1 0.2-3 MHz 0.77 mH 180 V-s 0.140
055663 100:1 0.2-3 MHz 3.1 mH 360 V-s 0.47
055664 200:1 0.2-3 MHz 12.4 mH 715 V-s 1.8

General Specifications

  • Operation Temperature: -30 to +125 (Temperature Rise Included)
  • Storage Temperature: -40 to +85
  • Temperature Rise: 40 C at rated Irms
  • Rated Current: 0.1 to 40 A

Product Dimensions

Dimensions: MM (INCHES)

  • AII EII EI AI: 12.60 0.50 (.496 .020)
  • Overall Length: 18.00 (.709) MAX.
  • Overall Width: 23.5 (.925) MAX.
  • Overall Height: 27 (1.063) MAX.
  • Lead Diameter: 0.60 (.024) SQ.
  • Mounting Hole Diameter: 3.00 (.118) DIA.
  • Internal Dimension: 17.5 (.689) MAX.
  • Dimension B: 8.89 0.50 (.350 .020)
  • Dimension C: 3.50 0.50 (.138 .020)
  • Dimension D: 10.16 0.50 (.400 .020)

Solder Profile

Profile Feature: Pb-Free Assembly

  • Average ramp-up rate: ~ 200 C/second
  • Heating rate during preheat: typical 1-2 /second max. 4 /second
  • Final preheat temperature: within 125 C of soldering temperature
  • Peak temperature (Tp): 260 C
  • Time within +0 C / -5 C of actual peak temperature: 10 seconds
  • Ramp-down rate: 5 C/second max.

Additional Information

Note: Specifications are subject to change without notice. Users should verify actual device performance in their specific applications.


2411192316_BOURNS-055664_C19945832.pdf
