Wirewound Power Resistor BOURNS W5M15R0J with Low Thermal Resistant Ceramic Core and RoHS Compliance
Wirewound Power Resistor BOURNS W5M15R0J with Low Thermal Resistant Ceramic Core and RoHS Compliance
Specifications
Type :
Wirewound Resistor
Resistance :
15Ω
Power(Watts) :
5W
Temperature Coefficient :
±300ppm/℃
Tolerance :
±5%
Operating Temperature :
-55℃~+200℃
Description :
Wirewound Resistor 15Ω 5W ±300ppm/℃ ±5% Through Hole,D6.5xL17.5mm Through Hole Resistors RoHS
Mfr. Part # :
W5M15R0J
Model Number :
W5M15R0J
Package :
Through Hole,D6.5xL17.5mm
Description

Product Overview

The W Series Wirewound Power Resistor is designed for high-performance applications, featuring a low thermal resistant ceramic core and E24 resistance values. These RoHS compliant resistors are available in a wide power range from 1 to 10 Watts, with a coating material that meets UL 94V-0 requirements. Ideal for use in smart meters, renewable energy systems, industrial equipment, power supplies/chargers, lighting, instruments/gauges, and white goods, this series offers reliability and durability.

Product Attributes

  • Brand: Bourns
  • Product Series: W Series
  • Core Material: Low thermal resistant ceramic
  • Lead Wire Material: Tin-plated copper wire
  • Coating Material: Meets UL 94V-0 requirements
  • Compliance: RoHS compliant*
  • Resistance Values: E24 series
  • Non-inductive version: Available upon request

Technical Specifications

Specification Details
Resistance Range See Popular Resistance Values Table
Tolerance 5 %
Operating Temperature -55 C to +200 C
Temperature Coefficient 300 ppm/C
Maximum Voltage P*R
Short Time Overload 2.5 times rated voltage, R/R(2 % 0.05 ) for 5 seconds
Solderability 245 3 C for 2.5 0.5 seconds, Over 95 % coverage
Resistance to Solder Heat 260 5 C for 10 1 seconds, R/R(1 % + 0.05 )
Dielectric Strength Test voltage >500 Vrms for >1 minute. Pass.
Insulation Resistance Test voltage >500 Vrms for 1 minute. >109
Load Life (Humidity) 40 2 C, 90 to 95 % RH. 1.5 hours ON, 0.5 hours OFF for 1000 hours at rated power. R/R (5 % + 0.05 )
Load Life (Standard) 70 2 C. 1.5 hours ON, 0.5 hours OFF for 1000 hours at rated power. R/R(5 % + 0.05 )

Packaging Specifications

Model Style Qty. per Box (Pcs.) Min. Order Quantity (Pcs.)
W1M Ammo Pack 1,000 5,000
W2M Ammo Pack 500 2,000
W3M Ammo Pack 500 2,000
W5M Ammo Pack 500 2,000
W7M Ammo Pack 500 2,000
W9M Bulk in Box 25 / 200 2,000
W10M Bulk in Box 25 / 200 2,000

Popular Resistance Values

Code R Value Code R Value
15R0 15 56R0 56
22R0 22 82R0 82
33R0 33 1000 100
39R0 39 1200 120
47R0 47 1500 150

Other E24 resistance values available upon request.

Dimensions

Model L (mm/in) D (mm/in) W (mm/in) T (DIA.) (mm/in)
W1M 9.5 1.0 (.374 .039) 3.0 1.0 (.118 .039) 28.0 3.0 (1.102 .118) 0.54 0.05 (.021 .002)
W2M 11.5 1.0 (.453 .039) 4.5 1.0 (.177 .039) 28.0 3.0 (1.102 .118) 0.70 0.05 (.028 .002)
W3M 15.5 1.0 (.610 .039) 5.5 1.0 (.217 .039) 28.0 3.0 (1.102 .118) 0.70 0.05 (.028 .002)
W5M 17.5 1.0 (.689 .004) 6.5 1.0 (.256 .039) 28.0 3.0 (1.102 .118) 0.75 0.05 (.030 .002)
W7M 24.5 1.0 (.965 .039) 8.5 1.0 (.335 .039) 38.0 3.0 (1.496 .118) 0.75 0.05 (.030 .002)
W9M 39.5 1.0 (1.555 .039) 8.5 1.0 (.335 .039) 38.0 3.0 (1.496 .118) 0.75 0.05 (.030 .002)
W10M 52.5 1.0 (2.067 .039) 8.5 1.0 (.335 .0039) 38.0 3.0 (1.496 .118) 0.75 0.05 (.030 .002)

* Larger body size available upon request.

How to Order

W [Power Rating] [Pin Style] [Resistance Code] [Tolerance]

Example: W3M22R0J

  • Product Series: W
  • Power Rating: 1, 2, 3, 5, 7, 9, 10 Watts
  • Pin Style: M = Axial Miniaturized Version
  • Resistance Code:
    • R<100 ohms: R represents decimal point (e.g., 56R0 = 56 ohms)
    • R100 ohms: First three digits are significant, fourth digit represents number of zeros (e.g., 1500 = 150 ohms)
  • Resistance Tolerance: J = 5 %

Note: Specifications are subject to change without notice. Users should verify actual device performance in their specific applications.
