Ceramic High Pass Filter Mini Circuits HFCW 5500 Plus with 1.75 Watt Power Handling and Compact Size
Ceramic High Pass Filter Mini Circuits HFCW 5500 Plus with 1.75 Watt Power Handling and Compact Size
Specifications
Cut-Off Frequency :
5.5GHz
Insertion Loss :
0.9dB
Type of Filter :
High-pass Filter
Description :
0.9dB SMD-6P,1.6x0.8mm Ceramic Filters RoHS
Mfr. Part # :
HFCW-5500+
Model Number :
HFCW-5500+
Package :
SMD-6P,1.6x0.8mm
Description

High Pass Filter CERAMIC HFCW-5500+

The HFCW-5500+ is a ceramic high pass filter designed for applications requiring a passband from 6100 MHz to 20000 MHz. Its ultra-wide stopband and LTCC construction provide repeatable performance in rugged environments. The filter's small 0603 form factor and wrap-around terminations make it ideal for dense PCB layouts and minimize parasitic effects. Key advantages include good rejection (45 dB typical), rugged ceramic construction, tiny size, good power handling (1.75W), and temperature stability. Applications include test and measurements, applications, and telecommunications and broadband wireless systems.

Product Attributes

  • Brand: Mini-Circuits
  • Model: HFCW-5500+
  • Material: Ceramic (LTCC Construction)
  • Certifications: +RoHS Compliant
  • Case Style: JC0603C
  • Size: 0603 (0.063" x 0.032" x 0.024")

Technical Specifications

ParameterFrequency (MHz)Min.Typ.Max.UnitsNotes
Stopband Rejection LossDC - 33003944dB1, 2
Stopband Rejection Loss3300 - 44002545dB1, 2
Cut-Off Frequency55003dB*
Passband Insertion Loss6100 - 74002.6dB2
Passband Insertion Loss7400 - 135000.91.5dB2
Passband Insertion Loss13500 - 200001.4dB2
Return Loss6100 - 740010dB2
Return Loss7400 - 1350015dB2
Return Loss13500 - 2000011dB2
Operating Temperature-55125C
Storage Temperature-55125C
RF Power Input@25C1.75W max.* Derate linearly to 0.5W at 125C ambient. Permanent damage may occur if any of these limits are exceeded. 1, 2

2411010938_Mini-Circuits-HFCW-5500-_C6207170.pdf
