Mini-Circuits LFCN-2600 Ceramic Low Pass Filter Offering Harmonic Rejection for Laboratory Equipment
Mini-Circuits LFCN-2600 Ceramic Low Pass Filter Offering Harmonic Rejection for Laboratory Equipment
Specifications
Cut-Off Frequency :
3.125GHz
Impedance :
50Ω
Type of Filter :
Low-pass Filter
Frequency - Center :
3.125GHz
Description :
50Ω 3.125GHz SMD3216-4P Ceramic Filters RoHS
Mfr. Part # :
LFCN-2600+
Model Number :
LFCN-2600+
Package :
SMD3216-4P
Description

Product Overview

The Mini-Circuits LFCN-2600+ is a ceramic low pass filter designed for applications requiring harmonic rejection, such as VHF/UHF transmitters/receivers and laboratory use. It features excellent power handling up to 10W, a compact size due to its LTCC construction, and temperature stability. This 7-section filter is protected by U.S. Patent 6,943,646.

Product Attributes

  • Brand: Mini-Circuits
  • Material: Ceramic (LTCC construction)
  • Certifications: +RoHS Compliant
  • Origin: USA (implied by P.O. Box and phone number)

Technical Specifications

ParameterFrequency (MHz)Min.Typ.Max.Units
Passband Insertion LossDC-26001.2dB
Frequency Cut-Off31253.0dB
VSWRDC-26001.2:1
Stop Band Rejection Loss375020dB
Stop Band Rejection Loss3900-660030
Stop Band Rejection Loss840020
VSWR3750-840020:1

Ratings

ParameterValueUnits
Operating Temperature-55 to 100C
Storage Temperature-55 to 100C
RF Power Input10W max. at 25C
