Mini-Circuits HFCN-1000 High Pass Filter Offering Performance with Low Insertion Loss and Good Rejection
Mini-Circuits HFCN-1000 High Pass Filter Offering Performance with Low Insertion Loss and Good Rejection
Specifications
Impedance :
50Ω
Frequency - Center :
2.54GHz
Description :
50Ω 2.54GHz SMD3216-4P Ceramic Filters RoHS
Mfr. Part # :
HFCN-1000+
Model Number :
HFCN-1000+
Package :
SMD3216-4P
Description

Product Overview

The HFCN-1000+ is a miniature LTCC High Pass Filter constructed with 12 layers, offering high repeatability of performance. It covers the frequency range of 1080-4000 MHz, providing low insertion loss and good rejection. Wrap-around terminations minimize performance variations due to parasitics.

Product Attributes

  • Brand: Mini-Circuits
  • Model: HFCN-1000+
  • Construction: LTCC (Low Temperature Co-fired Ceramic)
  • Termination: Wrap-around
  • RoHS Compliance: +Suffix identifies RoHS Compliance
  • Case Style: FV1206

Technical Specifications

ParameterFrequency (MHz)Min.Typ.Max.UnitsNotes
Stop Band Rejection LossDC-57040dB
DC-74020dB
DC-74020:1VSWR
1080-40002.0dBPass Band Insertion Loss
1150-37001.4dBPass Band Insertion Loss
Freq. Cut-Off10003.0dB
VSWR1080-40001.5:1
RF Power Input25C7WDerate linearly to 3W at 100C ambient. Permanent damage may occur if any of these limits are exceeded.
DC Block Voltage1kVTypical
Operating Temperature-55100C
Storage Temperature-55100C

Key Features

  • Small Size (3.20mm x 1.6 mm): Allows for high layout density of circuit boards, while minimizing affects of parasitics.
  • Rejection peaks at harmonic frequencies: Provides good rejection of signals at harmonic frequencies, for improved system performance.
  • Wrap around termination: Provides excellent solderability and easy visual inspection capability.
  • LTCC construction: Provides a rugged package that is well suited for tough environments including high humidity and high temperature extremes.

The Big Deal

  • Low cost
  • Small size
  • 7 sections
  • Temperature stable
  • DC block in/out, breakdown voltage, 1kV typ.
  • Excellent power handling, 7W
  • Hermetically sealed

Applications

  • Sub-harmonic rejection
  • Transmitters/receivers
  • Lab use

2506301330_Mini-Circuits-HFCN-1000-_C4990147.pdf
