Mini-Circuits BFCN-2975 LTCC Band Pass Filter with 2975 MHz Center Frequency and Low Insertion Loss
Mini-Circuits BFCN-2975 LTCC Band Pass Filter with 2975 MHz Center Frequency and Low Insertion Loss
Specifications
Impedance :
50Ω
Insertion Loss :
2.2dB
Type of Filter :
Bandpass Filter
Bandwidth :
2570MHz~3440MHz
Frequency - Center :
2.975GHz
Description :
50Ω 2.2dB 2570MHz~3440MHz 2.975GHz SMD3216-4P Ceramic Filters RoHS
Mfr. Part # :
BFCN-2975+
Model Number :
BFCN-2975+
Package :
SMD3216-4P
Description
Product Overview

Mini-Circuits BFCN-2975+ LTCC Band Pass Filter is constructed with multiple layers to achieve a miniature size and high repeatability of performance. Wrap-around terminations minimize variations in performance due to parasitics. Covering 870 MHz passband, these units offer low insertion loss and good rejection.

Product Attributes
  • Brand: Mini-Circuits
  • Material: LTCC (Low Temperature Co-fired Ceramic)
  • Case Style: FV1206
  • Termination: Wrap around
Technical Specifications
ParameterFrequency (MHz)Min.Typ.Max.Units
Passband Center Frequency2975MHz
Insertion Loss2570 - 34402.23dB
Return Loss2570 - 34406.07.4dB
Stop Band, Lower RejectionDC - 17002026dB
Stop Band, Upper Rejection4000 - 75002026dB
Operating temperature-55C100C
Storage temperature-55C100C
RF Power Input@25C1.5W
Key Features
  • Small Size, 1206: Allows for high layout density of circuit boards, while minimizing the effects of parasitics.
  • Wrap around termination: Provides excellent solderability and easy visual inspection capability.
  • LTCC construction: Provides a rugged package that is well suited for tough environments including high humidity and high temperature extremes.
  • Rugged Power handling: Handles up to 1.5 Watts in a small package.
Applications
  • Harmonic Rejection
  • Transmitters / Receivers
  • and Avionics
Outline Dimensions
Inchesmm
A .1263.20
B .0631.60
C .0370.94
D .0200.51
E .0320.81
F .0090.23
Wt. grams .020

2410311338_Mini-Circuits-BFCN-2975-_C4989883.pdf
