Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Wire Wound Common Mode Choke Walsin WTCF2012Z0M221PB Ideal for USB Lines and Peripheral Applications
Specifications
Impedance @ Frequency :
220Ω@100MHz
Voltage Rating - DC :
50V
Number of Lines :
2
DC Resistance(DCR) :
400mΩ
Operating Temperature :
-40℃~+125℃
Current Rating :
300mA
Description :
220Ω@100MHz 2 400mΩ 0805 Common Mode Chokes RoHS
Mfr. Part # :
WTCF2012Z0M221PB
Model Number :
WTCF2012Z0M221PB
Package :
0805
Description

Product Overview

The ASC WTCF2012 Series is a wire-wound type common mode choke designed for excellent solderability. It is suitable for applications such as USB lines in personal computers and peripherals, as well as USB 2.0, IEEE1394, and LVDS interfaces.

Product Attributes

  • Brand: ASC
  • Type: Common Mode Choke
  • Series: WTCF2012
  • Certifications: RoHS

Technical Specifications

SeriesZ (OHM) @100MHz 20%DCR MAX. ()RATE CURRENT (mA)Cut-off Frequency (GHz) TYP.Rated Voltage (Vdc)Withstand Voltage (Vdc)Insulation Resistance @125VDC (MOHM) MIN.Packing Code
WTCF2012Z0M670PB670.254001.05012510P
WTCF2012Z0M750PB750.304001.05012510P
WTCF2012Z0M900PB900.353301.05012510P
WTCF2012Z0M101PB1000.353301.05012510P
WTCF2012Z0M121PB1200.303701.05012510P
WTCF2012Z0M161PB1600.353501.05012510P
WTCF2012Z0M181PB1800.353301.05012510P
WTCF2012Z0M201PB2000.403001.05012510P
WTCF2012Z0M221PB2200.403001.05012510P
WTCF2012Z0M261PB2600.403001.05012510P
WTCF2012Z0M361PB3600.503001.05012510P
WTCF2012Z0M371PB3700.452801.05012510P
WTCF2012Z0M431PB4300.552801.05012510P
WTCF2012Z0M601PB6000.602401.05012510P
WTCF2012Z0M751PB7500.902201.05012510P

Shape and Dimension

SERIESM1M2M3M4
WTCF20122.00.21.200.21.200.20.40(TYP.)

Ordering Information

WT CF 2012 Z0 M 670 P B
Product Code Series Dimensions Series extension Tolerance Value Packing Code


2411061720_Walsin-WTCF2012Z0M221PB_C3248320.pdf
