Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Common mode choke wire wound type Walsin WQCF2012Z0M371PB for noise suppression in usb and data lines
Specifications
Operating Temperature :
-40℃~+125℃
DC Resistance(DCR) :
450mΩ
Voltage Rating - DC :
50V
Number of Lines :
2
Description :
450mΩ 2 0805 Common Mode Chokes RoHS
Mfr. Part # :
WQCF2012Z0M371PB
Model Number :
WQCF2012Z0M371PB
Package :
0805
Description

Product Overview

The WQCF2012 Series is a wire-wound common mode choke designed for noise suppression in USB lines and high-speed data interfaces. It offers excellent solderability and is AEC-Q200 certified, making it suitable for automotive applications.

Product Attributes

  • Brand: Walsin
  • Certification: AEC-Q200
  • Origin: Not specified
  • Material: Not specified
  • Color: Not specified

Technical Specifications

SeriesDimensions (W x L x H) mmImpedance (OHM) @100MHz 20%DCR MAX. ()RATE CURRENT (mA)Cut-off Frequency (GHz) TYP.Rated Voltage (Vdc)Withstand Voltage (Vdc)Insulation Resistance @125VDC (MOHM) MIN.Operating Temperature RangePacking Code
WQCF2012Z0M670PB2.0 x 1.2 x 0.40(TYP.)670.254001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M750PB2.0 x 1.2 x 0.40(TYP.)750.304001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M900PB2.0 x 1.2 x 0.40(TYP.)900.353301.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M101PB2.0 x 1.2 x 0.40(TYP.)1000.353301.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M121PB2.0 x 1.2 x 0.40(TYP.)1200.303701.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M161PB2.0 x 1.2 x 0.40(TYP.)1600.353501.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M181PB2.0 x 1.2 x 0.40(TYP.)1800.353301.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M201PB2.0 x 1.2 x 0.40(TYP.)2000.403001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M221PB2.0 x 1.2 x 0.40(TYP.)2200.403001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M261PB2.0 x 1.2 x 0.40(TYP.)2600.403001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M361PB2.0 x 1.2 x 0.40(TYP.)3600.503001.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M371PB2.0 x 1.2 x 0.40(TYP.)3700.452801.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M431PB2.0 x 1.2 x 0.40(TYP.)4300.552801.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M601PB2.0 x 1.2 x 0.40(TYP.)6000.602401.05012510-40 ~ +125P (7 Reeled)
WQCF2012Z0M751PB2.0 x 1.2 x 0.40(TYP.)7500.902201.05012510-40 ~ +125P (7 Reeled)

2411061720_Walsin-WQCF2012Z0M371PB_C3248312.pdf
