customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
customized clamping forceforklift solid tyre press/tire vulcanizing machine
Specifications
Place of Origin :
Jiangsu, China
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
Gearbox, Pressure vessel
Brand Name :
Geekung
Machine Type :
Plate Vulcanizing Press
Voltage :
220V/380V/415V/440V
Dimension(L*W*H) :
1820x1066x3760
Weight :
30000
Warranty :
1 Year
Key Selling Points :
Famous brand PLC
Showroom Location :
Turkey
Applicable Industries :
Manufacturing Plant
Color :
Custom Made
Power(W) :
22.5KW
After-sales Service Provided :
Field installation, commissioning and training
After Warranty Service :
Video technical support
Certification :
CE,ISO
Marketing Type :
Hot Product 2019
Packaging Details :
export package
Port :
Shanghai
Supply Ability :
10 Set/Sets per Quarter
Price :
$10,000.00/sets >=1 sets
Payment Terms :
T/T
Description

Product Description

(rubber plate press, rubber hot plate press,rubber curing press,hot press for pvc flooring,rubber plate vulcanizing press,hot press for rubber,plate vulcanizing press for rubber,press machine for kinds of rubber products,like rubber mat,rubber plate,rubber flooring,pvc flooring,solid tire,etc.)

Specification

Technical parameter

Model

Q812x812x2

Q900x900x1

Q1066x1066x1

Q1200x1200x1

Q1500x1500x1

Name

Solid tire press

Solid tire press

Solid tire press

Solid tire press

Solid tire press

Nominal clamping force (MN)

2.5

5.0

7.5

6.0

12.0

Plate size(MM)

812x812

900x900

1066x1066

1200x1200

1500x1500

Unit pressure of the plate(Mpa)

3.8

6.2

6.6

4.2

5.3

Dayligh opening(MM)

775

736

832

520

520

Layers

2

1

1

2

2

Max.piston stroke(MM)

965

736

863

600

600

Plunger diameter(MM)

500

650

600

650

900

Work hydraulic pressure(Mpa)

13

15

15

18

19

Max.steam pressure(Mpa)

0.8

0.8

0.8

0.8

0.8

Motor power(KW)

7.5

13

22.5

13

26

Dimension(MM)

1340x812x4110

1500x900x3310

1820x1066x3760

2200x1400x44000

2520x1500x51100

Weight(T)

12

19

30

20

44
