15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
Specifications
Place of Origin :
Jiangsu, China
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Motor, Pump
Brand Name :
Geekung
Machine Type :
Vacuum Vulcanizing Press
Voltage :
220V/380V/415V/440V/480V
Dimension(L*W*H) :
3830x2450x2990
Weight :
13000 KG
Warranty :
1 year
Key Selling Points :
Long Service Life
Showroom Location :
Turkey
Applicable Industries :
Manufacturing Plant
After-sales Service Provided :
Engineers available to service machinery overseas
Power(W) :
15KW
Marketing Type :
Ordinary Product
After Warranty Service :
Video technical support, Spare parts, Field maintenance and repair service
Local Service Location :
Turkey
Certification :
CE,ISO
Packaging Details :
plastic film packed and loaded in a whole container.
Port :
Shanghai
Supply Ability :
30 Set/Sets per Month
Price :
$30,000.00 - $99,999.00/sets
Payment Terms :
T/T
Description

Product Description

Hydraulic Compression Molding Press/Rubber Hydraulic Vulcanizing Machine/Rubber Vacuum Compression Molding Press/Compression Moulding Machine:

APPLICATIONS:
Ideal for the production of making rubber gaskets, O-rings, keyboards, medical stoppers, medical rubber products, seal, wipers scraping head, sports ,rubbe seals,etc.
REMARKABLE FEATURES:
· The vacuum suction hood provides highly efficient vacuum suction effect for the entire mold inside the working platen, suction speed of 700HG/2 sec. The unit offers simplified construction, easy to operate and maintain, with fast mold change.
· Integrated hydraulic circuit provide various pipe functions on the circuit boards, reducing piping to a minimum. The oil cooler ensures long service life of the circuit valve.
· The motion time, traverse and number of motions can be conveniently set on the control panel to meet product variations, ensuring production quality.
· Combines two molding units in one machine, which can be operated separately.
· While in vulcanization molding operations, the hydraulic pump motor can be set for running, or stopped for power saving.
· The electric system is controlled by the PLC controller, allowing for easy operation and accurate adjustment. An emergency switch provides added safety for the mold and the operator.

Specification

Model JC-PV80T-2 JC-PV150T-2 JC-PV200T-2 JC-PV250T-2 JC-PV300T-2
Clamping Force TON 80 150 200 250 300
Plate Size mm 380×420 450×450 500×550 550×550 650×650
Piston Stroke mm 380 345 380 380 380
Heating Capacity kw 9 9 13.5 20.4 20.4
Pump Motor kw 5.5 7.5 7.5 11 15
Piston Diameter mm 230 356 495 406 430
Max Mold Size
L×W×H 		mm 340×380 ×180 410×410 ×120 510×510 ×200 510×510 ×200 610×610 ×175
Machine Dimensions mm 2850×1625 ×2610 3150×1640×2550 3650×1800×3090 3650×1800×3090 3830×2450×2990
Machine Weight kg 6500 7200 9300 11000 13000

Finished Products

15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production15KW Rubber Vacuum Compression Molding Press for 13000 KG Large Scale Production
