Four Columns Hydraulic Forming Press 1000T For Automotive Exhaust Pipe
Four Columns Hydraulic Forming Press 1000T For Automotive Exhaust Pipe
Specifications
Brand Name :
XINKE
Certification :
CE, ISO9001:2000
Place of Origin :
China
MOQ :
1 Unit
Price :
USD 50000-1000000 Per Unit
Payment Terms :
L/C, T/T
Supply Ability :
8 Units Per Months
Delivery Time :
90-180 Working Days
Packaging Details :
Wooden case, waterproof cover
Frame :
Staight sided
Drive :
Oil Hydraulic
Control :
PLC
Application :
Pipe Fittings, Tube Fittings, Automotive Exhaust
Feature :
Multi-directional forming
Description

YST 1000T Hydraulic Automotive Exhaust Pipe Forming Press

Features:

  1. Finite element analyzed straight sided frame and four columns frame, high rigidity and precision
  2. Latest electro-hydraulic proportional control technology. Slider position, pressure, working force, working speed can be preset.
  3. Mitsubishi PLC, touch screen
  4. Operation mode: Manual, automation
  5. For 90 degree elbows, 135 degree elbows, side cylinders are used
  6. Light curtain safety protection device
  7. Ultrahigh pressure system is used

Application:

Suitable for the process of various type of carbon steel or stainless steel pipe & tube fittings, such as tees, reducers, elbows.

Technical Data:

Item Unit YST-1000
Nominal force kN 10000
Force of lateral cylinder kN 8000*2
Working pressure of medium Mpa 25
The opening daylight mm 1500
Stroke of slider mm 800
Stroke of lateral cylinder mm 400
Worktable height above the floor mm 600
Distance between left lateral cylinder and right lateral cylinder mm 1400
Lateral cylinder height above worktable mm 400
Speed of slider Descend mm/s 60
Working mm/s 1/6
Return mm/s 80
Speed of two lateral cylinder mm/s 3/6
Motor power Kw 51.5
Overall size of machine F.B. mm 4250
L.R. mm 6650
Height above the floor mm 5780
Frame type 　 Straight sided
