Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2
Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2
Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2
Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2
Specifications
Brand Name :
Jiayan
Model Number :
UCQ2
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 sets per week
Delivery Time :
7 days
Packaging Details :
inner poly bag and outer carton box
Material :
Aluminum Alloy
Max. operating pressure :
10 kgf/cm2
Min. operating pressure :
1 kgf/cm2
Range of temperature :
-10 ~ +60 °C
Range of stroke(mm) :
Max:50
Magnetic piston :
optional
Description

Thin Type Pneumatic Cylinder Automatic Machine Aluminum Alloy Air Cylinder Max Operation Force 10 kgf/cm2

Feature and Specifications:

Cylinder inside diameter(mm) Φ12 Φ16 Φ20 Φ25 Φ32 Φ40 Φ50 Φ63 Φ80 Φ100
Stroke(mm) 5 ,10 ,15 ,20 ,25 ,30 ,35 ,40 ,45 ,50
Range of stroke(mm) Max:30 Max:50
Range of temperature (°C ) -10 ~ +60 °C

Max. operating pressure: 10 kgf/cm2

Min. operating pressure: 1 kgf/cm2

NOTE

Magnetic piston(optional).
Stroke in more than 50 mm belongs to special custom.

Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2

Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2

Long Stroke Pneumatic Cylinders Thin Type Max Operation Force 10 Kgf/Cm2
