BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
Specifications
Brand Name :
Seric
Model Number :
BZZ Series
Certification :
CE, ISO
Place of Origin :
Guangzhou, China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
5000
Delivery Time :
1-15 days
Packaging Details :
Carton Box/Wooden Case
After Warranty Service :
Online Support
OEM :
Accept
Condition :
100% Brand-new
Quality :
High-Quality
Application :
Industrial Machinery
Selling Units :
Single item
Description

Hydraulic steering control unit(SCU) is widely used both in the steering system of vehicles and the marine rudder. The operator can obtain a bigger steering control force with less steering force, and its function is more safe and reliable, its operation is more smooth and flexible.

Features

BZZ1, BZZ2, BZZ3 series SCU offers the advantages as follows:

1. This kind of SCU series can help you reduce machinery cost without mechanical linkage devices, and can offer reliable and light structure.

2. This kind of SCU series can operate more flexibly with light steering torque.

3. This kind of SCU series can offer emergency manual steering in case of engine failure.

4. This kind of SCU series can be steering at continuous speed with less steering torque.

5. This kind of SCU series can offer various hydraulic systems and different mounting choices.

6. This kind of SCU series can link various steering pumps and hydraulic steering systems.

Main Specification

Type Displacement
(mL/r)		 Flow
(L/min)		 Max.input pressure
(MPa)		 Max. cont. back pressure
(MPa)		 Weight
(kg)
BZZ□ - E50 * 50 4 16 2.5 4.72
BZZ□ - E63 * 63 5 4.85
BZZ□ - E80 * 80 6 5
BZZ□ - E100 * 100 7.5 5.27
BZZ□ - E125 * 125 9.5 5.43
BZZ□ - E160 * 160 12 5.75
BZZ□ - E200 * 200 15 6.08
BZZ□ - E250 * 250 19 6.48
BZZ□ - E280 * 280 21 6.78
BZZ□ - E315 * 315 24 7.13
BZZ□ - E400 * 400 30 7.78
BZZ□ - E500 * 500 38 8.67
BZZ□ - E630 * 630 48 9.72
BZZ□ - E800 * 800 60 11.18
BZZ□ - E1000 * 1000 75 12.8

Note 1: □Prepresents Function Code, BZZ2 can be chosen for SCU with the displacement of 50-200mL/r. BZZ1 or BZZ3 can be chosen for SCU with the dispplacement of 50-1000mL/r.

Note 2: "Flow" that we suggest to use is the flow of 1.25 times as much as that at the steering wheel's rotation speed of 60 r/min. If the design of the system can't meet the requirements, the flow is allowed to be adjusted a little bit.

Order Code

BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series

BZZ Series Hydraulic Orbital Motor Cycloid Hydraulic Motor BZZ1 BZZ2 BZZ3 Series
