48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
48 Frame Condenser Fan Motor - 1/3HP 460V 60HZ 1075RPM
Specifications
Brand Name :
trusTec
Model Number :
YDK-250-6A66-NKL
Certification :
UL CE
Place of Origin :
Changzhou, China
MOQ :
200 pcs
Price :
Negotiable (FOB/CNF/CIF)
Payment Terms :
T/T,L/C
Supply Ability :
100,000 pcs per month
Delivery Time :
15 days fresh products after order confirmation.
Packaging Details :
Standard carton packing, foam board inside for protection.
Product :
Condenser Fan Motor
Frame :
48 frame
Enclosure Type :
TEAO(Totally Enclosed Air Over)
Supply Voltage :
460V
Thermal Overload :
Equipped With An Automatic Thermal Overload
Supply Frequency :
60HZ
Phase :
Single Phase
Current :
1A
Mounting :
Bracket
Output Power :
250W 1/3HP
Bearings :
Ball Bearing
Speed :
1075RPM
Mounting Orientation :
All Angle
Poles :
6P
Insulation Class :
Class B
Max. Ambient Temperature :
40℃/104℉
Capacitor :
7.5μF/450V
Flat Length :
127mm/5.00"
Rotation :
CCW-CW
Shaft Length :
154mm/6.06"
Shaft Diameter :
12.7mm/0.5"
Screw Length :
14mm/0.55"
Lead Length :
700mm/27.56"
Description

Tips

A NEMA 48 frame motor is a fractional horsepower (FHP) motor, typically around 5.5 inches in diameter with a 1/2-inch shaft, often used in HVAC/R and pumps, and is distinguished by its thru-bolt spacing (3-5/8 inches for bracket mounts) and often uses suffixes like 'Y' or 'Z' for mounting variations (e.g., 48Y, 48Z), making them compact replacements for older motors.

Key Dimensions & Characteristics

  • Diameter: Approximately 5.5 inches.

  • Shaft Diameter: Usually 1/2 inch.

  • Shaft Height: About 3 inches (for rigid bases).

  • Thru-Bolt Spacing (Bracket Mount): 3-5/8 inches.

  • Common Horsepower: Often 1/2 HP or 3/4 HP.

  • Speeds: Can be single-speed or multi-speed (e.g., 2-speed).

  • Suffixes: 'Y' or 'Z' indicate variations like square flanges or specific mounting, common in pool pumps (48Y/56Y).

How to Identify & Measure

  • Measure Thru-Bolts: For bracket-mounted motors, measure the distance between the thru-bolts; 3-5/8" indicates a 48 frame.

  • Check Nameplate: Look for "48" or suffixes like "48Y," "48Z" on the motor's spec label.

  • Measure Diameter: A motor body diameter of roughly 5.5 inches is a strong indicator.

Common Applications

  • HVAC/R: Condenser fans, furnace blowers.

  • Pool Pumps: Often interchangeable with 56 frame motors in specific configurations (48Y/56Y).
