Our enameled wire complies fully with JIS standards and adopts upgraded formulations, delivering steady performance across dimension, mechanics, electricity, heat resistance and self-bonding properties.

• Strict tolerance control: unilateral deviation ≤ 0.001mm, with CPK ≥ 1.33 to ensure stable mass production.
• Fixed 0.040mm conductor diameter with tiny size fluctuation, enabling seamless winding alignment.

• High tensile strength and ductility prevent wire breakage during high-speed winding, suitable for compact tight coil production.
• Abrasion resistance is 1.3 times higher than standard JIS requirements; scratch-proof coating protects wires during processing.

• F-class thermal resistance up to 155°C, maintaining stable performance under overload conditions.
• Direct solderable at 300–340°C; clean laser and mechanical stripping guarantees high soldering yield.
• Great insulation, corrosion and radiation resistance for harsh working environments.

• Coils can be firmly bonded via heat (110–220°C) or solvent activation, no extra adhesive needed.
• Uniform bonding strength for all specs, perfectly matching integrated molded inductors production.

We adopt high-efficiency single-head production lines with superior dimensional stability, equipped with two full-process monitoring systems:

• HVC high-voltage continuity pinhole monitoring: Full inspection to guarantee complete insulation coating.
• 360° laser real-time diameter monitoring: Zero dimensional defects throughout production.

100% full inspection on dimension, insulation and bonding performance for every batch. Complete batch traceability system ensures long-term product reliability.

Q2.What fields are your productsmainly used in?

A :We mainly produce ultra-fine enameled wire. Our products are widely used in automobiles, new energy, electric power, communication, home appliances, and other fields as winding coils for motors, generators, transformers, and other equipment. We also cooperate with famous brands such as Huawei, Xiaomi, BYD Foxconn, and so on.

Q3.Do you have your own product design?

A :Yes. We can design and improve materials, processes, and performance to meet customer process needs and winding requirements.

Q4.If we provide materials, can you do the secondary processing? What other services can you provide?

A :If it meets the requirements of the production process, we can assist in secondaryprocessing.① Besides mass production, we can also provide customized production in small quantities with multiple specifications.② We can provide technical support according to the customer's product requirements, to assist the customer in completing the research and development of new products.

Q5.Where is your factory located? How far is it from Guangzhou/Beijing/Shanghai/Shenzhen?

A :We have 2 production bases: ① Xianning base: close to Wuhan, in the center of China. The time to Guangzhou, Beijing, Shanghai, and Shenzhen by high-speed rail is about 3-4 hours; the airplane is about 1.5 hours; ②Dongguan base: close to Guangzhou and Shenzhen, farther away from Beijing and Shanghai, about 4 hours by airplane.
