AWG29 0.287mm 1UEW Solderable Polyurethane Enameled Copper Wire Red Wire 180 Grade
AWG29 0.287mm 1UEW Solderable Polyurethane Enameled Copper Wire Red Wire 180 Grade
Specifications
Insulated Outer Diameter (mm) :
0.326~0.338
Model Number :
1UEW-H
Electrical resistance（Ω/m20℃） :
0.2541~0.2698
MOQ :
200kg
Delivery Time :
15 work days
Payment Terms :
T/T,Western Union,Paypal
Supply Ability :
Satisfy your Demand
Elongation (%) :
≥40
Certification :
RoHS/HF
Thermal Shock :
≤ 2S/390±5℃
Place of Origin :
China
Solderability :
Solderable 390℃, 2s
Price :
For Negotiation
Breakdown Voltage (≥V) :
1200
Brand Name :
Huaye New Material
Packaging Details :
Spool with Cartoon
Description
Round Enameled Copper Wire

Round enameled copper wire is manufactured with high-purity copper and premium enamel insulation to deliver excellent electrical conductivity, mechanical strength, and winding performance. It is widely used in motors, transformers, inductors, relays, coils, and various electromagnetic components.

Parameter Typical Value
Conductor Diameter 0.287 mm
Overall Diameter 0.330 mm
DC Resistance (20°C) 0.262 Ω/m
Breakdown Voltage ≥11.8 kV
Tensile Strength 291–294 MPa
Elongation 44–48%

Typical values are based on production inspection results and are provided for reference only. Custom wire diameters, insulation grades, and thermal classes are available upon request.
