DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
Specifications
Brand Name :
XRTOOLS
Model Number :
1mm-20mm
Certification :
ISO9000
Place of Origin :
JIANG SU
MOQ :
500PCS
Price :
0.05-2.7$/PCS
Payment Terms :
T/T, L/C, D/P
Supply Ability :
400,0000Pcs Per Mouth
Delivery Time :
30-45days
Packaging Details :
Plastic box,Double Blister card
Name :
hSS Cobalt bits
Material :
High Speed Steel, HSS
Type :
Twist Drill Bit
Process :
Fully Ground
Size :
1-20mm,
Shank :
Hex Shank
Hardness :
HRC65-67
Surface :
Bright, Titanium coating, black etc.
Point angle :
118 Degree
Use :
Soft Metal Wood, Plastic Drilling
Description

DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling

quick datail :

1 Name: DIN / ANSI HSS Twist Drill Bit
2 Material: High Speed Steel, HSS
3 Process: Fully Ground (Rolled & Polished, Rolled, Milled are Available)
4 Size: Size: 3-13mm, 1/8"-1/2"
5 Point Type: 118 Degree
6 Shank Type: Hex Shank (Straight Shank, Tri-Flats Shank, Double R Hex Shank, Reduced Shank)
7 Helix Angle: Regular Spiral Type N
8 Surface Finish: Titanium Coating, other finish available too

size :

Diameter (mm) Flute Length (mm) Overall Length (mm) Diameter (mm) Flute Length (mm) Overall Length (mm)
4.0 43 75 8.0 75 117
4.2 43 75 8.5 75 117
4.5 47 80 9.0 81 125
9.5 81 125 15.0 114 169
10.0 87 133 15.5 120 178
10.5 87 133 16.0 120 178
12.0 101 151 17.5 130 191
12.5 101 151 18.0 130 191
13.0 101 151 18.5 135 193

DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling

How to Sharpen the HSS Drill Bit?

You can Sharpen the HSS Drill Bit when the chipping length is below 0.02,” or

drilled holes are out of the tolerance. When the drilling produces more noise is

another sign of sharpening. You can use a file or grinder made with carbide or

diamond. The cutting angle should maintain according to the material requirement.

Workpiece Material Point Angle Helix Angle Lip Relief Angle
Aluminum 90 to 135 32 to 48 12 to 26
Brass 90 to 118 0 to 20 12 to 26
Cast iron 90 to 118 24 to 32 7 to 20
Mild Steel 118 to 135 24 to 32 7 to 24
Stainless Steel 118 to 135 24 to 32 7 to 24
Plastics 60 to 90 0 to 20 12 to 26

DIN / ANSI Hex Shank HSS Saw Drill Bit For Soft Metal Wood Plastic Drilling
