Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
Specifications
Name :
high speed steel drill bits,
Material :
M35,M42
Type :
Twist Drill Bit
Process :
Fully Ground
Size :
11mm
Shank :
Straight Shank
Hardness :
HRC65-67
Surface :
Amber Finished
Point angle :
118 Or 135 Degree Split Point
Use :
copper,Carbon Steel,Cast Iron
Standard :
DIN 338,DIN / ANSI / Aircraft
Packing :
Customize
Brand Name :
XRTOOLS
Model Number :
1mm-18mm
Certification :
ISO9000
Place of Origin :
JIANG SU
MOQ :
500PCS
Price :
0.05-2.7$/PCS
Payment Terms :
T/T, L/C, D/P
Supply Ability :
400,0000Pcs Per Mouth
Delivery Time :
30-45days
Packaging Details :
Plastic box,Double Blister card
Description

M42 Straight Shank DIN338 HSS Drill Bits For Metal With Amber Finished

Description

HSS drill bits are used to drill soft materials such as aluminum, brass, mild steel, plastic, hardwood, softwood, fiber, etc.

Coated HSS bits can be used to drill cast iron and many more tough materials.

1 Material:M35,M42

2. Process:Fully Ground

3. Surface:Black Oxide

4. Point:18°/135°split point

5. Shank:Straight Shank

6. Drilling holes on aluminium,plastic,wood,copper,iron,stainless steel

HSS Drill Bits of Size:

D(mm) L2(mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm)
0.88 11 32 3.6 39 70 8.7 81 125 13.9 108 160
0.9 11 32 3.7 39 70 880 81 125 14 108 160
0.92 11 32 3.8 43 75 8.9 81 125 14.25 114 169
0.95 11 32 3.9 43 75 9 81 125 14.5 114 169
0.98 12 34 4 43 75 9.1 81 125 14.75 114 169
1 12 34 4.1 43 75 9.2 81 125 15 114 169
1.05 12 34 4.2 43 75 9.3 81 125 15.25 120 178
1.1 14 36 4.3 47 80 9.4 81 125 15.5 120 178
1.15 14 36 4.4 47 80 9.5 81 125 15.75 120 178
1.2 16 38 4.5 47 80 9.6 87 133 16 120 178
1.25 16 38 4.6 47 80 9.7 87 133 16.25 125 184
1.3 16 38 4.7 47 80 9.8 87 133 16.5 125 184
1.35 18 40 4.8 52 86 9.9 87 133 16.75 125 184
1.4 18 40 4.9 52 86 10 87 133 17 125 184
1.45 18 40 5 52 86 10.2 87 133 17.25 130 191
1.5 18 40 5.1 52 86 10.3 87 133 17.5 130 191

What is a ​ drill bits?

High-speed steel (HSS) drill bits can drill wood, fiberglass, polyvinyl chloride (PVC) and soft metals such as aluminum.

Cobalt drill bits are extremely hard and dissipate heat quickly. They're mostly used for boring in aluminum and

tough metals such as stainless steel

  • Premium M42 8% Cobalt Steel ,68-70 HRC (Rockwell Hardness Scale) ,Usually Give the Best Heat,Wear and Chip Resistance and Long Tool Life.
  • For Cutting through Stainless Steel,Hard Metals,Aluminum,Plastic,and Hard Wood.
  • This Cobalt Drill Bit is Typically Capable of Running Three to Five Times Faster.Despite the Higher Price,the Cost Per Hole When Using Cobalt Drill Bit Will be the Lowest,Since It Can Produce So Many More Holes.
  • The Sufficiently Sharp Bit Edge Can Cut the Metal Material into Long Strips of Iron Chips rather than Slowly Grinding through the Material with a Blunt Drill Bit.

Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished

Packing:

Each hss drill bit packing in palstic box.

Straight Shank M42 DIN338 HSS Drill Bits For Metal With Amber Finished
