CE Low Voltage Battery Pack 19.2kWh 48V100Ah Domestic PV Battery Storage
CE Low Voltage Battery Pack 19.2kWh 48V100Ah Domestic PV Battery Storage
Specifications
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$3200-3400
Color :
white
Rated Voltage :
48V
Description
19.2kWh Lithium-Ion Stack Battery System for Residential PV Storage
Flexible expansion & stack design, LEP48V/100Ah
Product Overview
This advanced lithium-ion battery system features a stackable design for flexible expansion and elegant appearance. With one-button system startup and side-hidden wiring for customer convenience, it directly communicates with mainstream inverter protocols. Comprehensive multi-level battery protection strategies and fault isolation measures ensure safe operation, making it ideal for small commercial and home energy storage applications.
Key Features
  • Bilingual display (Chinese/English) showing all pack information
  • Direct selection of inverter communication protocol via screen
  • One-button system startup and shutdown
  • Stackable design enables flexible battery expansion
  • Multiple cluster parallel connection - supports up to 8 battery packs in parallel
Manufacturing Advantages
Factory Direct Supply: Own production base with direct order processing ensures supply efficiency
Flexible Production Capacity: Support for small batch trial orders (MOQ 1 unit)
Customization Service: Product parameters (voltage, interface) can be customized according to customer requirements
CE Low Voltage Battery Pack 19.2kWh 48V100Ah Domestic PV Battery Storage
Technical Specifications
Model CH--GLV1-P20
Battery Module Model LFP48V/100Ah
Battery Module Nominal Energy 4.8 kWh
Rated Voltage 48 V
Number of Cell Modules in Single Cluster 4
Single Cluster Battery Energy 19.2 kWh
Maximum Number of Clusters in Parallel 8
Operating Voltage Range 42-54.75 V
Recommended Charging Voltage 51.75 V
Recommended Discharge Cut-off Voltage 45 V
Maximum Charge/Discharge Current 0.5C
Unit Cluster Size (D×W×H) 425×700×1056 mm
Unit Cluster Weight 254 kg
Communication Mode CAN/485/Bluetooth
Operating Temperature -30°C to 60°C (Recommended: 10°C to 35°C)
Storage Temperature -20°C to 65°C (Recommended: 10°C to 35°C)
Humidity <85% RH
Protection Level IP20
Cooling Method Natural Air Cooling
Cycle Life ≥5000 cycles
Safety Standards CE, UN38.3, MSDS
