28.8kWh Low Voltage Battery Pack Stackable PV Battery Backup
28.8kWh Low Voltage Battery Pack Stackable PV Battery Backup
Specifications
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$4100-4300
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Color :
white
Rated Voltage :
48V
Description
28.8kWh Lithium-ion Battery Stack System
Flexible expansion stack design for residential PV storage - LFP48V/200Ah
Product Overview
This advanced lithium-ion battery stack system features a modular stacked design for flexible expansion and elegant appearance. With one-button system startup and side-hidden wiring for convenient operation, it directly supports mainstream inverter protocols for seamless communication. Comprehensive multi-level battery protection strategies and fault isolation measures ensure safe system operation, making it ideal for small commercial and residential energy storage applications.
Key Features
  • Bilingual Chinese/English display with comprehensive PACK information summary
  • Direct inverter communication protocol selection via display interface
  • Master switch for one-touch system operation
  • Modular stack design enables flexible battery capacity expansion
  • Multiple cluster parallel connection supporting up to eight battery packs
Manufacturing Advantages
Factory Direct Supply
Own production base with direct order processing for optimal supply efficiency
Flexible Production Capacity
Support for small batch trial orders (MOQ 1 unit)
Customization Service
Product parameters (voltage, interface) customizable to customer requirements
28.8kWh Low Voltage Battery Pack Stackable PV Battery Backup
Technical Specifications
Parameter Specification
Model CH--GLV2-P30
Battery Module Model LFP48V/200Ah
Battery Module Nominal Energy 9.6 kWh
Rated Voltage 48 V
Number of Cell Modules in Single Cluster 3
Single Cluster Battery Energy 28.8 kWh
Maximum number of Clusters in Parallel 8
Operating Voltage Range 42-54.75 V
Recommended Charging Voltage 51.75 V
Recommended Discharge Cut-off Voltage 45 V
Maximum Charge/Discharge Current 0.5C
Unit Cluster Size (D×W×H) 479×700×1128 mm
Unit Cluster Weight 324 kg
Communication Mode CAN/485/Bluetooth
Operating Temperature -30°C to 60°C (Recommended 10°C to 35°C)
Storage Temperature -20°C to 65°C (Recommended 10°C to 35°C)
Humidity <85% RH
Protection Level IP20
Cooling Method Natural Air Cooling
Cycle Life ≥5000 cycles
Safety Standards CE, UN38.3, MSDS
