1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter
1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter
Specifications
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$200-$500
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Noise :
≤50dB
Operating Temperature :
-10°C-50°C
Operating Environment Humidity :
-10°C-60°C
LCD Interface :
can display operating mode/load/input/output
Max Charging Current :
100A
Max AC Charging Current :
60A
Description
Home Energy Storage Off-grid Inverter 1.6kW Pure Sine Wave Wall-mounted Installation
1.6kW Off-Grid Solar Inverter for Home Energy Storage System
Product Highlights
  • Pure Sine Wave Output, Compatible with Various Loads - Utilizes ultra-high frequency technology for pure sine wave output, providing stable and interference-free power supply that safely drives refrigerators, air conditioners, precision electrical appliances and other equipment
  • Intelligent MPPT Control, Improved PV Utilization - Integrates high-precision MPPT solar controller with working voltage range of 30-450VDC and maximum PV open-circuit voltage of 500VDC, significantly enhancing solar panel power generation efficiency
  • Compatible with Multiple Battery Types - Flexible energy storage configuration options
  • Wall-mounted Design, Easy and Safe Installation - Lightweight body with wall-mounted structure for easy installation and transportation; equipped with non-power-off parallel machine auxiliary function for safer installation
Application Scenarios
  • Suitable for small household PV systems to achieve self-consumption and surplus power storage, reducing reliance on mains power
  • Supplies power to small household appliances and lighting equipment in remote areas such as villages and mountainous regions with inconvenient mains power access
  • Used as emergency power supply for households and small shops to ensure operation of critical equipment during mains power failures
Others
  • Factory Direct Supply - Own production base with direct order processing to ensure supply efficiency
  • Flexible Production Capacity - Support for small batch trial orders (MOQ 1 unit)
  • Customization Service - Product parameters (such as voltage, interface) can be customized according to customer requirements

1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter

1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter 1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter1.6kW Off Grid Solar Inverter Pure Sine Wave 100A Off Grid Power Inverter
Model

CH-ED2012EMH

AC Input AC Input Voltage 220VAC (standard) / 110VAC (Custom)
Input Voltage Range oltage 90~280VAC±3V( Normal Mode)
170~280VAC±3V( UPS Mode)
Input Frequency 50/60Hz±5%
Rated Output Power (Battery Mode) 1600W

Output		 Rated Output Power (PV Mode) 1600W
Output Voltage 220/230/240VAC±5%
Output Frequency 50/60Hz±0.1%
Output Wave Pure Sine Wave
Transfer Time ≤10ms(UPS)/≤20ms(INV)
Peak Power 3200VA
Overload Ability Battery Mode:1ls@105%-150% Load
2s@150%-200% Load 400ms@200% Load
Battery Rated Voltage 12Vdc
Constant Charging Voltage (Adjustable) 14.1Vdc
Float Charging Voltage (Adjustable) 13.5Vdc

Charger		 PV Charging Mode MPPT
Max PV Input Power 2000W
MPPT Input Voltage Range 30-500Vdc
Optimal VMP Range 300-400Vdc
Max PV Input Voltage 500Vdc
Max PV Input Current 13A
Max PV Charging Current 100A
Max AC Charging Current 60A
Max Charging Current 100A

Display		 LCD Interface can display operating mode/load/input/output

Interface		 RS232 2400 Baud Rate 2400

Expansion Slot Communication Interface
Lithium Battery BMS Communication Card, WIFI/Pitch2.54mm
parallel interface Not support Parallel
Ambient Temperature Operating Temperature -10°C-50°C
Operating Humidity -10°C-60°C
Storage Temperature 20%-90% Non Condensing
Noise ≤50dB
