Easy To Install Industrial Water Filter System 90t/H Ultra Pure Water System
Easy To Install Industrial Water Filter System 90t/H Ultra Pure Water System
Easy To Install Industrial Water Filter System 90t/H Ultra Pure Water System
Easy To Install Industrial Water Filter System 90t/H Ultra Pure Water System
Specifications
Brand Name :
HongJie
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
>1set
Price :
US$168700~US$174500
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Water Quality :
Resistivity ≥≥18.24 MΩ·cm
Flow Rate :
75m³/H (Customizable)
Core Process :
Double-pass Reverse Osmosis + EDI + Polishing Resin
Key Components :
RO Membrane Modules, EDI Units
Electricity Supply :
380V/22oV
After-Sales Service :
2-Year Warranty
Operation Mode :
Fully Automatic
Product Features :
Stable Water Quality,Low Operation Cost,Reliable Performance
Desalination :
99.5%
TOC :
<0.1 ppb
Description

Easy To Install Industrial Water Filter System 90t/H Ultra Pure Water System For Preparation Of Electronic-Grade Chemicals

I. Overview
Ultra-pure water is an indispensable raw material in the preparation of electronic-grade chemicals (such as high-purity etching solutions, photoresists, and CMP slurries). Its purity directly affects the control of metal impurities, particle size distribution, and batch stability in electronic chemicals.
In the preparation of electronic-grade chemicals, ultra-pure water is not only a solvent but also a molecular-level clean reaction environment (extreme purification, system anti-pollution, performance engine).

II. Process

Raw Water → Pretreatment: UF + Softening → Primary RO → Secondary RO → Membrane Degassing→ EDI → UV + TOC Degradation → Ultra - precision Mixed Bed( Nuclear - Grade Resin) → Terminal Ultrafiltration(0.01 μm )→ Nitrogen - Sealed Circulation

III. Ultra-pure water limit parameters (SEMI C63 standard)

Parameter Standard Requirement
Resistivity (25°C) ≥18.24 MΩ·cm
TOC <0.1 ppb
Dissolved Oxygen (DO) <0.5 ppb
Particles (≥0.05μm) <0.5 particles/mL
Trace Metals
- Na⁺/K⁺ ≤0.01 ppt
- Fe/Cu/Ni ≤0.02 ppt
- B ≤0.005 ppt
Anions (Cl⁻/SO₄²⁻) ≤0.01 ppt

IV. Application Scenarios
Wet electronic chemicals (hydrofluoric acid, ammonia water)
Lithography materials (EUV photoresist, developer)
CMP polishing slurry (silicon dioxide/cerium oxide slurry)
Electroplating solution (electroplating solution)

V. Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
