Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System
Specifications
Brand Name :
Hongjie
Model Number :
HJ-UP1T
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
1set
Price :
negotiation
Payment Terms :
T/T,Western Union
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depend on raw materials stocking)
Packaging Details :
export standard wooden case
Voltage :
380V, 220V/50HZ etc; (Power supply can be Customized)
warranty :
1 Year
Control :
Automatic or manual
Power :
2-10 kw
Material :
SU304 Steel, Container
Capacity :
1m3-1000m3/Day
Usage :
Water Purification
core components :
Gearbox, Pressure vessel, Pump, Gear, Bearing, Engine, motor, PLC
Description

Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System

I.Product Specification

Function

Drinking water, Bottle water, Industrial water, Commercial water

System

Reverse osmosis system, Ultrafiltration system, EDI ultrapure system,

Water reuse system, Seawater desalination, Brackish water
desalination

Capacity

250/500/750/1000LPH, 2TPH, 3TPH, 4TPH, 5TPH, etc

Voltage

380V, 220V/50HZ etc; (Power supply can be Customized)

Power

2-10 kw

Raw Water

TDS ≤ 1000PPM
Working temperature: 0 ≤ 45°C
Well water, tap water, seawater, salt water, brackish water

Produced water quality

Conductivity ＜10μs/cm
Total organic carbon ≤ 0.5mg/L
Microorganism ＜100cfu/ml

Desalination rate

96-99%

Water recovery rate

50-70%

Work pressure

Pretreatment: 0.2—0.4MPa, RO host: 0.8—1.6Mpa

Material

FRP tank, Stainless steel 304, PVC pipe,

Control

Automatic or manual

Process

Quartz sand filter → Activated carbon filter → Water softener → High pressure pump → Ro system → UV → Ozone generator

II.Product Overview

Reverse osmosis (RO) is a process that separates pure water from contaminants through one or more layers of fine-porous semipermeable membranes. This technology is essential in most water purification systems. It is considered a highly effective method for removing impurities from water, such as toxic heavy metals like lead and radium, mercury, chlorinated pesticides, organic matter, turbidity, dissolved solids, bacteria, and viruses.

III.Product Flowchart

Raw water - Raw water tank - Raw water pump - Sand filter - Carbon filter - Water softener (optional) - Security filter - Booster pump - Reverse osmosis system - Water tank - Booster pump - EDI - Transfer pump - Polishing resin - Pure water tank - Water supply point

IV. Replacement Time for Consumable Parts

a. Quartz sand: Replace approximately every 15 months.

b. Activated carbon: Replace approximately every 15 months.

c. Resin: Replace approximately every 15 months.

d. PP filter element: Replace approximately every month.

e. RO membrane: Replace approximately every 2 years.

We recommend that customers purchase a 1-2 year old PP filter element with the machine, as these filters need to be replaced monthly.

Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System

Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System

Industrical 5TPH Reverse Osmosis Equipment RO Water Treatment System


ldentify needs

Clarify the following issues, you can determine the right equipment for you

Water quality problems

Example 1: sediment exceeds the standard / scale / turbid water / microbial exceeds the standard/ heavy metal exceeds the standard / money Yu exceeds the standard, etc.

Water standard

Example 1:Softened water/pure water/ultra-pure water/iron and manganese removal/sediment removal/sterilisation etc.

Daily Water Consumption

Example 1:Whether there is a concentrated water consumption period/water consumption time/peak maximum water consumption/hourly average water consumption

Conclusion Example

5 tonnes per hour water softening equipment.

3 tonnes per hour reverse osmosis water purification equipment

If you can't answer the above questions clearly?

1.Daily Water Consumption:Just mail a bottle of water sample

2.Water Standard:Just tell me your industry.

3.Water Consumption:We can help you to calculate the water consumption.
