FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
FRP Industrial Water Treatment Equipment 20m3h Ultra Pure Water Purification System
Specifications
Brand Name :
HongJie
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
>=1sets
Price :
US$44000~US$44500
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Water Quality :
resistivity ≥ 18.2 MΩ·cm
Flow Rate :
20m³/H (Customizable)
Core Process :
UF+2-stage RO + EDI + Polishing Resin
Key Components :
UFfilter ， RO Membrane Modules, EDI Units
Electricity Supply :
380V/220V
After-Sales Service :
2-Year Warranty
Operation Mode :
Fully Automatic
Pressure resistance :
150 psi
Description

I.Overview
FRP (Fiberglass Reinforced Plastic) is positioned as a “large-capacity storage + corrosion-resistant pretreatment” solution in ultra-pure water (resistivity ≥ 18.2 MΩ·cm) systems. Its hygiene and economic efficiency have been verified in the system, where it is mainly used in storage tanks, pretreatment equipment, piping systems, and wastewater treatment. Its core advantages are corrosion resistance, no pollution release, and high structural strength.

II.Standard Process
Raw Water → Raw Water Tank → Booster Pump → Flocculant/Reducer Dosing → Activated Carbon Filter → Ultrafiltration (UF) → Scale Inhibitor Dosing → Security Filter → 1st Stage High-Pressure Pump → 1st Stage RO → pH Adjustment → Intermediate Tank → 2nd Stage High-Pressure Pump → 2nd Stage RO → Purified Water Tank → EDI Booster Pump → UV Sterilizer → Cartridge Filter → EDI System → Ultra-Pure Water Tank → Transfer Pump → TOC Removal Unit → Polishing Resin → Final Filter → Point of Use

III.Application of FRP in Ultra - pure Water Treatment Systems

Application Areas Details
Application in Pretreatment Systems Filter Vessels FRP is widely used for the shells of multi - media filters, water softeners, and activated carbon filters
Pressure Vessels for Ultrafiltration (UF) Systems FRP pressure vessels carry ultrafiltration membrane modules and are widely used in seawater desalination and wastewater recycling
Application in Storage Ultra - pure Water Storage Tanks FRP storage tanks are one of the preferred containers for storing ultra - pure water, especially suitable for fields with high - purity water quality requirements such as electronics and pharmaceuticals

IV.FRP Advantageous Fields
Ultra-pure water storage tanks
Pre-treatment filters
Wastewater treatment tanks
Seawater desalination pressure vessels

V.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
