Specifications
Brand Name :
HongJie
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Guangdong,China
MOQ :
>=1sets
Price :
negotiation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Flow Rate :
2000L/H
Core Process :
Double-pass Reverse Osmosis + EDI + Polishing Resin
Pretreatment :
Quartz sand/activated carbon/water softener/PP filter
Operation Mode :
Fully Automatic
Type :
Reverse Osmosis Filtration
Usage :
Reverse Osmosis Water Treatment Industrial Filter
Product name :
Water Treatment System Processing Reverse Osmosis
Keywords :
Water Filter System Large Industry
Description

I. Product Introduction

Ultra-pure water equipment is a specialized device that employs multi-stage precision treatment processes to remove nearly all impurities from water, including ions, organic compounds, colloids, microorganisms, particles, etc., thereby producing ultra-pure water with extremely high resistivity (typically ≥18 MΩ·cm at 25°C). Its core objective is to meet the requirements of industries and fields that are extremely sensitive to water quality, such as semiconductors, pharmaceuticals, precision electronics, and high-end scientific research.

II. Design Standards & Compliance

  1. Custom Engineering: Based on your detailed water analysis report.
  2. Industry Certifications:
    • NB/T 10790-2021 (Technical Specifications for Water Treatment Equipment)
    • GB/T 19249-2017 (Reverse Osmosis Water Treatment Equipment)
    • IEC 439-1 (Low Voltage Switchgear and Controlgear Assemblies)
    • GB 6682-2008 (Laboratory Ultra-Pure Water Standards)
    • GB/T 11446.1-2013 (Electronic Grade Water Specifications)

III. Process Flow Diagram

Standard Configuration:
Raw Water → Raw Water Tank → Booster Pump → Flocculant/Reducer Dosing → Activated Carbon Filter → Ultrafiltration (UF) → Scale Inhibitor Dosing → Security Filter → 1st Stage High-Pressure Pump → 1st Stage RO → pH Adjustment → Intermediate Tank → 2nd Stage High-Pressure Pump → 2nd Stage RO → Purified Water Tank → EDI Booster Pump → UV Sterilizer → Cartridge Filter → EDI System → Ultra-Pure Water Tank → Transfer Pump → TOC Removal Unit → Polishing Resin → Final Filter → Point of Use
2 Stage 2000L/Hour Ultra Pure Water Systems EDI Ultrapure Water Ultrafiltration Equipment
2 Stage 2000L/Hour Ultra Pure Water Systems EDI Ultrapure Water Ultrafiltration Equipment

Process Highlights:

  • Multi-Stage Pretreatment: Removes particles, organics, and chlorine to protect RO membranes.
  • Dual RO System: Achieves salt rejection rate for consistent high-purity water.
  • EDI Technology: Continuous electro-deionization eliminates the need for chemical regeneration.
  • Polishing Resin: Final purification stage for ultralow TOC and ionic contaminants.

IV. Design Advantages

  1. Fully Automated Control:
    • Automatic backwash and regeneration cycles.
    • Manual override option for maintenance.
  2. Factory-Integrated Wiring:
    • Pre-wired components reduce on-site installation time .
  3. Advanced Maintenance Features:
    • RO chemical cleaning system extends membrane life.
    • Recirculation loops ensure water quality stability.
  4. Premium Materials:
    • 304 stainless steel and UPVC piping for corrosion resistance.
  5. Intuitive Operation:
    • Integrated control panel with real-time monitoring.
    • Remote access option for troubleshooting.
  6. Low Maintenance:
    • Durable components designed for continuous operation.

Contact us today to discuss your specific requirements and receive a customized solution proposal.

Hongjie Water Technology - Your Trusted Partner for Semiconductor Ultra-Pure Water Solutions
