1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
Specifications
Brand Name :
KEGU
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Model Number :
Customizable
Material :
SiC
Composition:SiC :
＞85%
Color :
Black
Density :
2.5~2.6g/cm³
Max. Service Temp :
1380℃
Flexural Strength :
70-90 MPa
Size :
Customized
Heat Conduction :
23.26 W/(m·℃)
Resistivity :
1000～2000 Ω·mm2/m
Tensile Strength :
39.2～49 MPa
Max. Service Temp. :
1500℃
Linear Thermal Expansion Coefficient (20-1500℃) :
5×10⁻⁶/℃
Electrical Resistivity :
1000~2000Ω·mm²/m
Description

1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements


The descrioition of sic heating element


1. The silicon carbide (SIC) heating element is a kind of non-metal high temperature electric heating element. It is made of selected super quality green silicon carbide as main material, which is made into blank, solid under high temperature and re-crystallized.
2. Compared with metal electric heating element, this element is characterized by high-applied temperature, anti-oxidization, anti-corrosion, long service life, little deformation, easy installation and maintenance.
3. Therefore, it is widely used in various high temperature electric furnaces and other electric heating devices, such as in the industries of magnet, ceramic, powder metallurgy, glass, metallurgy and machinery etc.


Physical property of SIC heating element

specific gravity
2.6~2.8g/cm³
bend strength
>300kg
hardness
>9MOH'S
tensile strength
>150kg/cm³
porosity rate
<30%
radiance
0.85


Application:

Widely used in research and production of glass, ceramic, refractory, metallurgy, steel-making, crystal, electronic parts,

semiconductor material.

Please tell us the following data when you order:


Type: U

Hot Zone: HZ

Cold Zone: CZ

Total Length: OL

Please mark terminal distance A.


FAQ:

Q: Are you trading company or manufacturer ?


A: We are factory which specialized in high-temperature heating elements (Mosi2 & Sic)and tungsten and molybdenum products for 16 years.


Q: How long is your delivery time?


A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples ? is it free or extra ?


A: Yes, we could offer the sample for free charge but do not pay the cost of freight.


Q: What is your terms of payment ?


A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us.


Quality control:1400°C Furnace Spiral Sic Heater Furnace Silicon Carbide Heating Elements
