ISO Transformer Turn Ratio Test Transformer Ratio Meter With CVT Function
ISO Transformer Turn Ratio Test Transformer Ratio Meter With CVT Function
ISO Transformer Turn Ratio Test Transformer Ratio Meter With CVT Function
ISO Transformer Turn Ratio Test Transformer Ratio Meter With CVT Function
Specifications
Place of Origin :
Wuhan Hubei China
Brand Name :
Huaying
Certification :
ISO
Model Number :
HYBC-901
MOQ :
1 Set
Price :
Negotiable
Packaging Details :
Wooden Case
Delivery Time :
7 Working Days
Payment Terms :
T/T L/C
Supply Ability :
200 sets per month
Advantage :
Added new function of CVT testing
Suitable :
For testing three or singe phase transformer
Function :
turn ratio measurement
Power supply :
AC220V ± 10%, 50Hz/60Hz
Product name :
Transformer Ratio Meter
Display :
LCD screen
Description

ISO Transformer Turn Ratio Test Transformer Ratio Meter With CVT Function

Product Name:

Transformer Ratio Meter HYBC-901

Technical Parameters:

1 Ratio measurement range:1~10000

2 Group measurement:1~12

3 Phase measurement error:1 degree

4 Ratio measurement error:1~2000 ± 0.2%RDG 2000~10000 ± 0.5%RDG

5 Test voltage:0~80V

6 Power supply:AC220V ± 10%, 50Hz/60Hz

7 Size 400´350´200 mm3 Weight 7kg Humidity: ≤85%RH

Equipment Description:

1 The voltage ratio measurement for three or singe phase transformer

2 The group vector measurement for three phase transformer.

3 The polarity measurement for single phase transformer or CT/PT

4 Voltage ratio error calculation

5 Current transformer ratio measurement

6 Excitation current measurement in ratio testing

7 Reproduction the AC test voltage from power source to reduce the effects of bad power source

8 Save the test results in the memory internal the tester

9 Print the test results by micro printer

10 Reverse connection detect unit to prevent the high voltage injected to operator

11 Over current protection unit integrated in software and hardware

12 Upload the test results to PC by RS232 and make word report by software
