13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional
Specifications
Brand Name :
OEM/Customized
Model Number :
ZH133BH005-01
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
13.3 Inch
Resolution :
1920x1080
Brightness :
250 cd/m² （Typ.）
Display type :
IPS, Normally Black
Outline Dimensions :
305.15(W) x178.01(H) x2.6(T) mm
Operating Temperature :
0℃~+50℃
Description

13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional


Meta Description
13.3-inch 1920x1080 full HD TFT LCD Screen with eDP interface, optional high brightness 250-1000 nits, wide temperature operation (-20~70°C), suitable for industrial control, medical devices, embedded systems, and outdoor applications.


The ZH133BH005-01 is high-performance 13.3-inch TFT LCD screen .offering full HD resolution (1920x1080) and IPS technology for superior color accuracy and wide viewing angles. Built for a variety of industries, this display provides crystal-clear visuals, making it ideal for industrial, medical, and commercial applications that require excellent performance in moderate environments.


Key Features

13.3-inch Full HD 1920x1080 resolution for crisp industrial and medical visuals

eDP interface, stable, low power, easy integration into embedded systems

IPS panel with full viewing angle, perfect for professional monitoring

Optional high brightness 250–1000 nits, suitable for bright indoor or semi-outdoor environments

Optional touch panel (CTP/RTP) for interactive industrial or medical equipment

Wide temperature operation: -20~70°C (storage -30~80°C), suitable for harsh environments

Long lifespan, high reliability, suitable for industrial, medical, and outdoor applications


Application

Industrial control panels, HMI displays

Medical monitoring devices, diagnostic equipment, lab instruments

Outdoor and semi-outdoor kiosks, POS terminals, vending machines

Embedded systems, IoT devices, UAV and robotics displays

Test instruments, laboratory and automation equipmen


Product Specification


Item Number ZH133BH005-01
Screen Size 13.3 Inch TFT LCD
Resolution 1920x1080
Brightness 250 cd/m²(Typ.)
Display Mode IPS, Normally Black
Interface EDP, 30pins Connector
Active Aera 293.76 (W) x 165.24 (H) mm
Outline Dimension 305.15(W) x178.01(H) x2.6(T) mm
Backlight white LED, 240mA 24V
Surface treatment Glare
Surface hardness 3H
Operating Temperature 0℃~+50℃
Storage Temperature -20℃~+60℃
Touch Panel Optional Touch Panel


Product Drawing

13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional

13.3 Inch TFT LCD Screen 1920x1080 eDP Interface Industrial Display Touch Optional


Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness


FAQ

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.


2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.


3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;


4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display


5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!


Call to Action :

  • Upgrade your device visibility with this premium TFT LCD Screen!

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Order Samples Now!
